Demo Deployments Rolling Updates and Rollbacks

In this lesson, you'll learn how to update and roll back deployments in Kubernetes. We'll start with a deployment definition file located in the "deployment" directory. The deployment, named "myapp-deployment", runs six replicas using the NGINX image.

Below is the deployment YAML definition:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp-deployment
  labels:
    tier: frontend
spec:
  selector:
    matchLabels:
      app: myapp
  replicas: 6
  template:
    metadata:
      name: nginx-2
      labels:
        app: myapp
    spec:
      containers:
        - name: nginx
          image: nginx

Creating the Deployment

First, check that there are no existing objects:

admin@ubuntu-server deployments # vi deployment.yaml
admin@ubuntu-server deployments # kubectl

Once confirmed, create the deployment using:

kubectl create -f deployment.yaml

After creating the deployment, check its rollout status:

kubectl rollout status deployment.apps/myapp-deployment

You should see an output like:

deployment "myapp-deployment" successfully rolled out

Keep in mind that if you check the rollout status immediately after creation, you might witness an intermediate state as Kubernetes updates each pod sequentially.

Demonstrating Rollout Status with Immediate Deletion

To better illustrate how the rollout process works, follow these steps:

1. Delete the current deployment:

   kubectl delete deployment myapp-deployment


2. Re-create the deployment:

   kubectl create -f deployment.yaml


3. Immediately check the rollout status:

   kubectl rollout status deployment.apps/myapp-deployment


You may encounter messages such as "0 of 6 updated replicas", "1 of 6 updated replicas", etc. Kubernetes waits until all six pods are running before marking the rollout as successful.

Checking Rollout History

Once the deployment is live, view its revision history with:

kubectl rollout history deployment.apps/myapp-deployment

Example output:

REVISION   CHANGE-CAUSE
1          <none>

Since the change cause was not recorded initially, the change cause column is empty.

Recording the Change Cause

To capture the reason behind changes, delete the existing deployment and re-create it using the --record option:

1. Delete the deployment and wait until all pods terminate:

   kubectl delete deployment myapp-deployment


2. Confirm deletion by checking the pods:

   kubectl get pods


3. Re-create the deployment with the record flag:

   kubectl create -f deployment.yaml --record


4. Monitor the rollout status:

   kubectl rollout status deployment.apps/myapp-deployment


After completion, verify the revision history:

kubectl rollout history deployment.apps/myapp-deployment

The output should now show an entry with a recorded change cause:

REVISION  CHANGE-CAUSE
1         kubectl create --filename=deployment.yaml --record=true

Updating the Deployment with kubectl edit

To update the deployment, start by viewing its details:

kubectl describe deployment myapp-deployment

Notice in the annotations section that the create command is recorded and the deployment is running six replicas of the NGINX image.

Now, update the container image interactively and record the change:

kubectl edit deployment myapp-deployment --record

In the editor, change the container’s image from nginx to nginx:1.18 (a lower version). An example edit might look like this:

maxUnavailable: 25%
type: RollingUpdate
template:
  metadata:
    creationTimestamp: null
    labels:
      app: myapp
      name: nginx-2
  spec:
    containers:
      - image: nginx:1.18
        imagePullPolicy: Always
        name: nginx
        resources: {}
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
    dnsPolicy: ClusterFirst
    restartPolicy: Always
    schedulerName: default-scheduler
    securityContext: {}
    terminationGracePeriodSeconds: 30

Save and exit the editor. Kubernetes will begin rolling out the update by gradually replacing the old pods with new ones that have the updated image. Monitor the progress with:

kubectl rollout status deployment.apps/myapp-deployment

Finally, check the rollout history to confirm the change:

kubectl rollout history deployment.apps/myapp-deployment

You should now see a new entry corresponding to the kubectl edit action.

Using kubectl set image for a Different Update Method

Another approach to update the container image is by using the kubectl set image command. For instance, to update the container image to nginx:1.18-perl, execute:

kubectl set image deployment myapp-deployment nginx=nginx:1.18-perl --record

Then, verify the rollout status:

kubectl rollout status deployment/myapp-deployment

The status messages will indicate that the old replicas for version 1.18 are being replaced by new replicas running version 1.18-perl. Confirm the updated revision history with:

kubectl rollout history deployment/myapp-deployment

Expected revision history:

REVISION  CHANGE-CAUSE
1         kubectl create --filename=deployment.yaml --record=true
2         kubectl edit deployment myapp-deployment --record=true
3         kubectl set image deployment myapp-deployment nginx=nginx:1.18-perl --record=true

Rolling Back to a Previous Revision

If the new image (version 1.18-perl) causes issues, you can easily roll back to a previous version. To revert from revision 3 to revision 2 (running NGINX 1.18), execute:

kubectl rollout undo deployment/myapp-deployment

Monitor the rollback process:

kubectl rollout status deployment/myapp-deployment

Once complete, confirm the current deployment configuration:

kubectl describe deployment myapp-deployment

Note that while the rollout history might show an updated revision number, the state will match the previous, stable revision.

Simulating a Failed Rollout

To demonstrate how Kubernetes handles a failed rollout, modify the deployment to use a non-existent image. Start by editing the deployment:

kubectl edit deployment myapp-deployment --record

Change the container image to an invalid name, such as nginx:1.18-does-n, as shown below:

maxUnavailable: 25%
type: RollingUpdate
template:
  metadata:
    creationTimestamp: null
    labels:
      app: myapp
      name: nginx-2
  spec:
    containers:
      - image: nginx:1.18-does-n
        imagePullPolicy: Always
        name: nginx
        resources: {}
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
    dnsPolicy: ClusterFirst
    restartPolicy: Always
    schedulerName: default-scheduler
    securityContext: {}
    terminationGracePeriodSeconds: 30

Save and exit the editor. At this point, check the rollout status:

kubectl rollout status deployment/myapp-deployment

In a separate terminal, you can inspect the deployment and pod statuses:

kubectl get deployments myapp-deployment
kubectl get pods

You will observe that while five pods continue running with the previous configuration, the new pods trying to run the invalid image show an "ErrImagePull" error.

Even with some pods failing, the application remains accessible via the running pods.

Rolling Back the Failed Deployment

The rollout history now includes a new revision (for example, revision 5) that reflects the failed update. To restore stability (rolling back to revision 4), run:

kubectl rollout undo deployment/myapp-deployment

Then, monitor the rollback progress:

kubectl rollout status deployment/myapp-deployment

Finally, verify that all pods are running the correct image version (NGINX 1.18) by checking the pods:

kubectl get pods

The pod status should look similar to:

NAME                                         READY   STATUS    RESTARTS   AGE
myapp-deployment-789c649f95-8s9gk              1/1     Running   0          12s
myapp-deployment-789c649f95-9xs8q              1/1     Running   0          9m5s
myapp-deployment-789c649f95-dkfm4              1/1     Running   0          9m7s
myapp-deployment-789c649f95-qtngw              1/1     Running   0          9m8s
myapp-deployment-789c649f95-rktrd              1/1     Running   0          9m8s
myapp-deployment-789c649f95-x9jf5              1/1     Running   0          9m4s

Review the complete rollout history to verify all revisions and their change causes:

kubectl rollout history deployment/myapp-deployment

Conclusion

In this lesson, you have learned to:

• Create a Kubernetes deployment using a YAML file.
• Monitor rollout progress using kubectl rollout status.
• Record change causes with the --record flag.
• Update the deployment interactively using kubectl edit and via the kubectl set image command.
• Simulate a failed rollout scenario with an invalid image.
• Roll back to a previous revision using kubectl rollout undo.

This approach ensures that your updates are applied smoothly and, if issues arise, can be quickly reverted to maintain application availability.

For further reading, consider exploring the Kubernetes Documentation and additional Kubernetes Basics.
