Enhance observability of your applications by tracking public internet performance with CloudWatch Internet Monitor. Learn how to diagnose latency issues, leverage anomaly detection, and integrate insights into your monitoring workflows.

1. Challenge: Diagnosing Public Internet Latency

Your application is hosted in an AWS US Region, while users in the UK and Europe typically see latencies between 40 ms and 100 ms. Occasionally they experience as low as 5 ms or spikes up to 70 ms. One day, a London user reports 900 ms latency, even though backend health checks remain steady at 100–200 ms.

Since your application metrics are healthy, the issue is likely somewhere on the public internet path. How can you pinpoint and resolve performance problems outside your AWS infrastructure?

2. Introducing Internet Monitor

CloudWatch Internet Monitor provides end-to-end visibility into internet traffic for your AWS resources. By analyzing real user network flow data, it helps you quickly identify and troubleshoot routing issues, ISP outages, or misconfigurations.

Key Features

Feature	Benefit
Monitor Network Flow	Track traffic patterns and performance across the public internet.
Source & Destination Analysis	Identify IP prefixes and autonomous systems affecting your traffic.
Anomaly Detection	Automatically surface spikes in latency, packet loss, or throughput.
AWS Service Integration	Correlate internet-path data with CloudWatch dashboards, alarms, and Logs.
Real-Time Visibility	View live network performance to troubleshoot issues immediately.
Thresholds & Alarms	Set custom alerts on latency, bandwidth, or active connections.
Detailed Traffic Records	Aggregate IP traffic data for security audits and compliance.

The image is an infographic titled "Internet Monitor," highlighting features such as monitoring network flow data, anomaly detection, AWS integration, real-time visibility, setting alarms, and supporting VPC flow logs.

Note

Ensure VPC Flow Logs are enabled and your IAM role has internetmonitor:* permissions before creating a monitor. See the CloudWatch IAM Policies for details.

Example: Enable Internet Monitor via AWS CLI

Replace the placeholders with your resource ARN and desired settings:

aws internetmonitor create-monitor \
  --monitor-name MyInternetMonitor \
  --resources "arn:aws:ec2:us-east-1:123456789012:vpc/vpc-0a1b2c3d4e5f6g7h" \
  --traffic-visibility "ALL" \
  --client-token "$(uuidgen)"

3. Real-World Use Case: Troubleshooting a Latency Spike

Alert Triggered
A CloudWatch alarm notifies you when latency exceeds 200 ms.
Path Analysis
Internet Monitor shows a European ISP with elevated packet loss and latency.
AWS Correlation
You confirm via CloudWatch metrics (ELB latency, EC2 network stats) that your backend is healthy.
Remediation
You coordinate with the ISP to resolve routing issues or update Route 53 to reroute traffic through a different edge location.

Warning

Continuous monitoring may incur additional data processing and transfer charges. Review CloudWatch Pricing to estimate costs.
