Demo Kubernetes Deployment Rollout

In this guide, we’ll enhance a Jenkins pipeline to deploy a Kubernetes application with proper rollout checks and automatic rollback on failure. By combining vulnerability scanning, dynamic image updates, and robust deployment scripts, you ensure that failed releases don’t leave your cluster in an unhealthy state.

Problem Statement

Our initial pipeline applied an updated Deployment manifest (including runAsUser: 100), but we never verified the rollout status. The kubectl apply command succeeded, yet the pods failed to start due to a misconfiguration. We need to:

• Scan manifests for security issues
• Apply or update the deployment
• Monitor rollout status
• Roll back automatically on failure

Kubernetes Manifest: k8s_deployment_service.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app: devsecops
  name: devsecops
spec:
  replicas: 2
  selector:
    matchLabels:
      app: devsecops
  strategy: {}
  template:
    metadata:
      labels:
        app: devsecops
    spec:
      containers:
        - image: replace
          name: devsecops-container
          securityContext:
            runAsUser: 100
---
apiVersion: v1
kind: Service
metadata:
  labels:
    app: devsecops
  name: devsecops-svc
spec:
  ports:
    - port: 8080
      protocol: TCP
      targetPort: 8080
  selector:
    app: devsecops
  type: NodePort

Initial Jenkinsfile Stages

stage('Vulnerability Scan - Kubernetes') {
    steps {
        sh 'docker run --rm -v $(pwd):/project openpolicyagent/conftest test --policy opa-k8s-security.rego k8s_deployment_service.yaml'
    }
}

stage('Kubernetes Deployment - DEV') {
    steps {
        withKubeConfig([credentialsId: 'kubeconfig']) {
            sh 'sed -i "s#replace:siddharth67/numeric-app:${GIT_COMMIT}#g" k8s_deployment_service.yaml'
            sh 'kubectl apply -f k8s_deployment_service.yaml'
        }
    }
}

Enhanced Jenkinsfile: Parallel Deploy and Rollout

We replace the simple apply step with two parallel branches:

1. Deployment: applies or updates the manifest
2. Rollout_Status: monitors the rollout and triggers rollback on failure

stage('Vulnerability Scan - Kubernetes') {
    steps {
        sh 'docker run --rm -v $(pwd):/project openpolicyagent/conftest test --policy opa-k8s-security.rego k8s_deployment_service.yaml'
    }
}

stage('K8S Deployment - DEV') {
    steps {
        parallel(
            Deployment: {
                withKubeConfig([credentialsId: 'kubeconfig']) {
                    sh 'bash k8s-deployment.sh'
                }
            },
            Rollout_Status: {
                withKubeConfig([credentialsId: 'kubeconfig']) {
                    sh 'bash k8s-deployment-rollout-status.sh'
                }
            }
        )
    }
}

post {
    always {
        junit 'target/surefire-reports/*.xml'
    }
}

Deployment Script: k8s-deployment.sh

This script replaces the placeholder image name, then either creates a new Deployment or updates the existing one with --record=true to capture change-cause.

#!/bin/bash
# Replace placeholder with real image name
sed -i "s|replace|${imageName}|g" k8s_deployment_service.yaml

# Check if deployment exists
if ! kubectl -n default get deployment "${deploymentName}" > /dev/null; then
    echo "Creating deployment ${deploymentName}"
    kubectl -n default apply -f k8s_deployment_service.yaml
else
    echo "Updating image for ${deploymentName} to ${imageName}"
    kubectl -n default set image deploy "${deploymentName}" "${containerName}"="${imageName}" --record=true
fi

Rollout Status Script: k8s-deployment-rollout-status.sh

After a short wait, this script checks the rollout status with a timeout. On failure, it issues a rollback to the previous revision.

#!/bin/bash
# Allow pods to initialize
sleep 60s

# Monitor rollout with a 5-second timeout
if ! kubectl -n default rollout status deploy "${deploymentName}" --timeout=5s | grep -q "successfully rolled out"; then
    echo "Rollout FAILED; rolling back ${deploymentName}"
    kubectl -n default rollout undo deploy "${deploymentName}"
    exit 1
else
    echo "Rollout SUCCESSFUL for ${deploymentName}"
fi

Jenkinsfile Environment Variables

Define all deployment-specific variables at the top of your Jenkinsfile for easy maintenance:

pipeline {
    agent any

    environment {
        deploymentName = 'devsecops'
        containerName  = 'devsecops-container'
        serviceName    = 'devsecops-svc'
        imageName      = "siddharth67/numeric-app:${GIT_COMMIT}"
        applicationURL = 'http://devsecops-demo.eastus.cloudapp.azure.com/'
        applicationURI = '/increment/99'
    }

    stages {
        stage('Build Artifact - Maven') {
            steps {
                sh 'mvn clean package -DskipTests=true'
                archive 'target/*.jar'
            }
        }
        stage('Unit Tests - JUnit and JaCoCo') {
            steps {
                sh 'mvn test'
            }
        }
        stage('Mutation Tests - PIT') {
            steps {
                sh 'mvn org.pitest:pitest-maven:mutationCoverage'
            }
        }
        stage('SonarQube - SAST') {
            steps {
                withSonarQubeEnv('SonarQube') {
                    sh 'mvn sonar:sonar \
                        -Dsonar.projectKey=numeric-application \
                        -Dsonar.host.url=http://devsecops-demo.eastus.cloudapp.azure.com:9000'
                }
            }
        }
        // ... Kubernetes stages go here ...
    }
}

Pushing Changes

Once scripts and Jenkinsfile are updated, commit and push:

Pipeline & Cluster Verification

In the pipeline logs for k8s-deployment.sh:

+ bash k8s-deployment.sh
deployment devsecops exists
image name = siddharth67/numeric-app:70a453a78462ec8affbf58f4ab3d566c2283
deployment.apps/devsecops image updated

The rollout branch confirms:

sh k8s-deployment-rollout-status.sh
# pods start and transition to RUNNING

On the Kubernetes cluster:

root@devsecops-cloud:~$ kubectl get all
NAME                           READY   STATUS    RESTARTS   AGE
pod/devsecops-abcdef123        1/1     Running   0          59s
pod/devsecops-ghijkl456        1/1     Running   0          61s
deployment.apps/devsecops      2/2     2         2          5m
...

If a pod fails to become Running, the rollback script will revert to the previous revision.

Viewing Rollout History

Inspect recorded change causes for debugging:

kubectl rollout history deploy devsecops
REVISION  CHANGE-CAUSE
1         <none>
2         <none>
...
23        kubectl set image deploy devsecops devsecops-container=siddharth67/numeric-app:70a453a78462ec8affbf58f4ab3d566c2283 --namespace=default --record=true

Using --record=true captures the exact kubectl command and Git commit, making audits and rollbacks straightforward.
