Welcome to this hands-on lab where we’ll configure the AppRole authentication method in HashiCorp Vault. By the end of this guide, you’ll be able to enable AppRole, create a role, and authenticate using a role_id and secret_id.

The image is a solid dark purple background with a few small white squares scattered on the right side.

Prerequisites

A running Vault server in development or production mode
Vault CLI installed and configured (vault login with a root or privileged token)
Basic familiarity with Vault policies and tokens

1. Check Enabled Auth Methods

List the authentication methods currently enabled in Vault:

vault auth list

Example output:

Path    Type    Accessor            Description
----    ----    --------            -----------
token/  token   auth_token_12345    token based credentials

Note

By default, Vault enables only the token auth method. You’ll add AppRole in the next step.

2. Enable AppRole

Enable AppRole at its default path (approle/):

vault auth enable approle

Expected response:

Success! Enabled approle auth method at: approle/

3. Create an AppRole

An AppRole ties Vault policies to applications or machines. Create a role named bryan that references the bryan policy and issues tokens valid for 20 minutes:

vault write auth/approle/role/bryan \
    policies=bryan \
    token_ttl=20m

Successful output:

Success! Data written to: auth/approle/role/bryan

Note

Adjust the token_ttl to match your security requirements. You can also set token_max_ttl to enforce a hard limit.

4. List AppRole Roles

Verify the roles available under the AppRole auth method:

vault list auth/approle/role

Example output:

Keys
----
bryan

5. Retrieve the Role ID

Each AppRole has a stable role_id. Fetch it with:

vault read auth/approle/role/bryan/role-id

Sample response:

Key      Value
---      -----
role_id  2d7d168a-806b-520d-40b6-597841cf8d42

6. Generate a Secret ID

Every login requires a one-time secret_id. Create it now:

vault write -force auth/approle/role/bryan/secret-id

You’ll see output similar to:

Key                 Value
---                 -----
secret_id           fe323f09-72db-1a83-1846-a150b669686c
secret_id_accessor  2e69247f-568a-70dc-c2a5-45a262eefc87
secret_id_ttl       0s

Warning

The generated secret_id is sensitive and should be transmitted securely. Consider customizing secret_id_ttl or using CIDR restrictions.

7. Log In with AppRole

Use the role_id and secret_id to authenticate and receive a Vault token:

vault write auth/approle/login \
    role_id=2d7d168a-806b-520d-40b6-597841cf8d42 \
    secret_id=fe323f09-72db-1a83-1846-a150b669686c

Sample response:

Key                  Value
---                  -----
token                s.20UtHiDfKIehjDfgMuEDkzB8
token_accessor       itew3hMdKQ6SAVNL38XZzB8
token_duration       20m
token_renewable      true
token_policies       ["bryan" "default"]
identity_policies    []
policies             ["bryan" "default"]
token_meta_role_name bryan

Note

When specifying parameters in the CLI, use underscores (role_id, secret_id). In API paths, hyphens appear in the endpoint (e.g., role-id, secret-id).

Summary

In this lab you have:

Enabled the AppRole auth method
Created a new role (bryan) linked to a Vault policy
Retrieved the stable role_id for that role
Generated a one-time secret_id
Authenticated with AppRole to get a Vault token

You can now use this token for subsequent Vault operations, such as reading secrets or managing dynamic credentials.
