Selectors Matchers

In this lesson, we explore how Prometheus uses selectors and matchers to filter time series data. When you query using a metric name like "node_filesystem_avail_bytes", Prometheus returns every time series that matches this metric. For example:

$ node_filesystem_avail_bytes
node_filesystem_avail_bytes{device="/dev/sda2", fstype="vfat", instance="node1", mountpoint="/boot/efi"}
node_filesystem_avail_bytes{device="/dev/sda2", fstype="vfat", instance="node2", mountpoint="/boot/efi"}
node_filesystem_avail_bytes{device="/dev/sda3", fstype="ext4", instance="node1", mountpoint="/"}
node_filesystem_avail_bytes{device="/dev/sda3", fstype="ext4", instance="node2", mountpoint="/"}
node_filesystem_avail_bytes{device="tmpfs", fstype="tmpfs", instance="node1", mountpoint="/run"}
node_filesystem_avail_bytes{device="tmpfs", fstype="tmpfs", instance="node1", mountpoint="/run/lock"}
node_filesystem_avail_bytes{device="tmpfs", fstype="tmpfs", instance="node1", mountpoint="/run/snapd/ns"}
node_filesystem_avail_bytes{device="tmpfs", fstype="tmpfs", instance="node1", mountpoint="/run/user/1000"}
node_filesystem_avail_bytes{device="tmpfs", fstype="tmpfs", instance="node2", mountpoint="/run"}
node_filesystem_avail_bytes{device="tmpfs", fstype="tmpfs", instance="node2", mountpoint="/run/lock"}
node_filesystem_avail_bytes{device="tmpfs", fstype="tmpfs", instance="node2", mountpoint="/run/snapd/ns"}
node_filesystem_avail_bytes{device="tmpfs", fstype="tmpfs", instance="node2", mountpoint="/run/user/1000"}

By default, all these time series are returned. However, if you are interested in a specific subset, label matchers allow you to narrow down the results by filtering based on individual label values.

Equality Matcher

The equality matcher returns all time series that have a specific label value. For instance, to filter time series from a specific instance like "node1", include the label filter within curly braces:

$ node_filesystem_avail_bytes{instance="node1"}
node_filesystem_avail_bytes{device="/dev/sda2", fstype="vfat", instance="node1", mountpoint="/boot/efi"}
...

This query returns only those series with the instance label set to "node1". Note that occasionally, other series might appear grayed out indicating they have been filtered out.

Negative Equality Matcher

The negative equality matcher helps exclude time series with a particular label value. For example, to filter out time series where the "device" label equals "tmpfs", you would use:

$ node_filesystem_avail_bytes{device!="tmpfs"}

This query returns time series where the device is not "tmpfs".

Regular Expression Matcher

For advanced filtering, you can use the regular expression matcher. Suppose you want to include only time series where the "device" label starts with "/dev/sda" (covering both "/dev/sda2" and "/dev/sda3"). In that case, you can run:

$ node_filesystem_avail_bytes{device=~"/dev/sda.*"}

The =~ operator signals that you are using a regular expression, where /dev/sda.* matches any value beginning with "/dev/sda".

Negative Regular Expression Matcher

Conversely, to exclude time series based on a regex pattern, you can apply the negative regular expression matcher. For example, to filter out any series where the mountpoint starts with "/boot", execute:

$ node_filesystem_avail_bytes{mountpoint!~"/boot.*"}

This query omits all time series with a mountpoint that starts with "/boot".

Combining Multiple Label Selectors

Prometheus supports combining multiple label selectors within a single query. For example, if you want time series from "node1" that do not have the device label "tmpfs", you can use:

$ node_filesystem_avail_bytes{instance="node1", device!="tmpfs"}

This combined query applies both filters concurrently to return the desired output.

Range Vector Selectors

Range vector selectors allow you to retrieve historical data for a time series over a specified duration. Unlike an instant vector that gives the most recent value, a range vector provides all values scraped over a given period. For instance, to view data for the "node_arp_entries" metric from "node1" over the last 2 minutes, you can use:

$ node_arp_entries{instance="node1"}[2m]
  8 @1669253129.609
  2 @1669253144.609
  3 @1669253159.609
  1 @1669253174.609
  7 @1669253189.609
  7 @1669253204.609
  6 @1669253229.609
  6 @1669253234.609

The suffix [2m] indicates that the query should return all values recorded over the past 2 minutes.

Summary

This lesson demonstrated how to:

• Use equality matchers to filter by specific label values.
• Apply negative matchers to exclude unwanted series.
• Employ regular expressions for flexible matching.
• Combine multiple label selectors for more refined queries.
• Utilize range vector selectors to retrieve historical metric data.

For further reading on Prometheus querying and label matching, check out the Prometheus Documentation.
