Composite Resources and Compositions

Imagine ordering a burger by listing every ingredient separately: the bun, the patty, lettuce, sauce — each item spelled out on its own. It’s tedious, and you’d need to know the whole recipe to place the order. A set menu fixes this.

A webpage UI titled "Order every ingredient — or just order the burger" with an à la carte checklist showing checked items: bun, patty, lettuce, and sauce. The right side has a "SET MENU" label.

Instead of listing every resource for an application environment (namespace, ConfigMap, storage, etc.), you want developers to request a single, higher-level resource. Crossplane provides that higher-level API through CompositeResourceDefinitions (XRDs) and Compositions. A Composition acts as the blueprint that builds the full infrastructure from a single request — like a kitchen assembling a burger from a set menu.

A graphic titled "One environment, many manifests" showing five stylized YAML file cards labeled namespace.yaml, configmap.yaml, storage.yaml and ...more.yaml. The cards are arranged with soft shadows on a white background.

Why use Compositions?

Reduce manifest sprawl and human error.
Provide a simple, consistent API for developers.
Let platform teams evolve implementations without changing developer workflows.
Enable self-service infrastructure by encapsulating complexity.

How it works

Define a CompositeResourceDefinition (XRD) that declares a new API (the composite type) and its schema.
Create a Composition that implements that API by specifying the concrete resources to provision and how request fields map into them (via patches and functions).
Developers create instances of the composite type (for example XSimpleApp) and Crossplane expands and manages all underlying resources.

Table: Key Crossplane resources

Resource Type	Purpose	Example
CompositeResourceDefinition (XRD)	Declares a custom composite API and validates request fields	`kind: XSimpleApp`
Composition	Blueprint that implements the XRD by creating concrete resources and wiring inputs	`compositeTypeRef: apiVersion: platform.example.org/v1 kind: XSimpleApp`

Example: a minimal XRD Below is a minimal CompositeResourceDefinition for an XSimpleApp. It declares the composite API, the requestable fields, and validation (here appName and environment are required; environment limits values to dev, staging, or prod).

apiVersion: apiextensions.crossplane.io/v1
kind: CompositeResourceDefinition
metadata:
  name: xsimpleapps.platform.example.org
spec:
  group: platform.example.org
  names:
    kind: XSimpleApp
  versions:
    - name: v1
      served: true
      referenceable: true
      schema:
        openAPIV3Schema:
          type: object
          properties:
            spec:
              type: object
              properties:
                appName:
                  type: string
                environment:
                  type: string
                  enum:
                    - dev
                    - staging
                    - prod
              required:
                - appName
                - environment

Example: a Composition (blueprint) A Composition implements the XRD by describing which concrete resources to create for every XSimpleApp instance. This example uses mode: Pipeline and a step that references a function for patching and transformations (details on functions/patching follow in later lessons).

apiVersion: apiextensions.crossplane.io/v1
kind: Composition
metadata:
  name: xsimpleapp
spec:
  compositeTypeRef:
    apiVersion: platform.example.org/v1
    kind: XSimpleApp
  mode: Pipeline
  pipeline:
    - step: resources
      functionRef:
        name: function-patch-and-transform
      input:
        resources:
          - name: namespace
            base:
              apiVersion: v1
              kind: Namespace
              metadata:
                name: placeholder-namespace
          - name: configmap
            base:
              apiVersion: v1
              kind: ConfigMap
              metadata:
                name: placeholder-configmap
              data:
                example: placeholder

Apply and observe

Apply the XRD first. Kubernetes will register a new composite resource type.
Apply the Composition. Platform owners manage Compositions; developers should not need to edit them.
When a developer creates an XSimpleApp, Crossplane expands that single request into the concrete resources defined by the Composition and reconciles them continuously.

Example kubectl get ns after Crossplane provisions a namespace for an XSimpleApp:

user@cluster:~$ kubectl get ns
NAME                   STATUS    AGE
default                Active    6d
crossplane-system      Active    2h
placeholder-namespace  Active    12s

Developer experience Developers only need to create and maintain instances of the composite API. For example, a developer requests an XSimpleApp with simple fields:

apiVersion: platform.example.org/v1
kind: XSimpleApp
metadata:
  name: demo-app
spec:
  appName: demo
  environment: prod

Crossplane will:

Create and manage the namespace and ConfigMap defined by the Composition.
Use functions/patches configured in the Composition to propagate request values (appName, environment) into the generated resources.
Reconcile and repair drift automatically.

XRDs and Compositions let platform teams expose a simplified API to developers. Platform owners maintain Compositions (the implementation blueprints), while developers create instances of the composite type. Functions and patches inside a Composition map request fields into generated resources to keep configuration DRY and consistent.

XRDs can be cluster-scoped or namespace-scoped. Choose the scope carefully: it determines where users can create composite instances and affects access control and lifecycle management.

Next steps

Try creating the XRD and Composition in a test cluster and then create an XSimpleApp instance to see Crossplane provision the underlying resources.
In follow-up lessons, learn how Composition functions and patching transform request fields into concrete resource fields and how to conditionally compose resources.
