Demo Configure URL Redirect

In this tutorial, you will learn how to enforce HTTPS by redirecting all HTTP requests (port 80) to HTTPS (port 443) using NGINX. We’ll demonstrate this on a simple diner app currently served over HTTP.

1. Verify the Current Setup

1. Open the diner app in your browser at http://localhost.
2. Check your firewall rules:

root@ubuntu-host# ufw status
Status: active

To                         Action      From
--                         ------      ----
22/tcp                     ALLOW       Anywhere
80/tcp                     ALLOW       Anywhere
22/tcp (v6)                ALLOW       Anywhere (v6)
80/tcp (v6)                ALLOW       Anywhere (v6)

Port 443 is not yet allowed, so accessing HTTPS returns a 502 Gateway error:

3. Allow HTTPS traffic:

root@ubuntu-host# ufw allow 443/tcp
root@ubuntu-host# ufw status
Status: active

To                         Action      From
--                         ------      ----
22/tcp                     ALLOW       Anywhere
80/tcp                     ALLOW       Anywhere
443/tcp                    ALLOW       Anywhere
22/tcp (v6)                ALLOW       Anywhere (v6)
80/tcp (v6)                ALLOW       Anywhere (v6)
443/tcp (v6)               ALLOW       Anywhere (v6)

Your firewall now permits port 443, but NGINX isn’t listening there yet.

2. Review Existing NGINX Configuration

List enabled sites:

root@ubuntu-host# ls -l /etc/nginx/sites-enabled
total 4
lrwxrwxrwx 1 root root 32 Feb  7 00:51 diner -> /etc/nginx/sites-available/diner

Open /etc/nginx/sites-available/diner—it currently listens only on HTTP:

server {
    listen 80;
    server_name diner.com;

    root /var/www/diner;
    index index.html index.htm index.nginx-debian.html;

    location / {
        # First attempt to serve request as file,
        # then as directory, then return a 404.
        try_files $uri $uri/ =404;
    }
}

3. Create the HTTPS Configuration

Create (or edit) /etc/nginx/sites-available/diner-https with two server blocks:

server {
    listen 80;
    server_name diner.com;

    # Redirect all HTTP requests to HTTPS
    return 301 https://$host$request_uri;
}

server {
    listen 443 ssl;
    server_name diner.com;

    # SSL certificates (already present on the system)
    ssl_certificate     /etc/ssl/certs/diner.com.pem;
    ssl_certificate_key /etc/ssl/certs/diner.com-key.pem;

    root /var/www/diner;
    index index.html index.htm index.nginx-debian.html;

    location / {
        # First attempt to serve request as file,
        # then as directory, then return a 404.
        try_files $uri $uri/ =404;
    }
}

4. Enable and Test the New Configuration

1. Disable the old site and enable the new one:

   root@ubuntu-host# sudo rm /etc/nginx/sites-enabled/diner
   root@ubuntu-host# sudo ln -s \
       /etc/nginx/sites-available/diner-https \
       /etc/nginx/sites-enabled/diner-https


2. Test NGINX syntax and reload:

   root@ubuntu-host# nginx -t
   nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
   nginx: configuration file /etc/nginx/nginx.conf test is successful

   root@ubuntu-host# nginx -s reload


3. Verify the redirect and HTTPS response:

   • HTTP → HTTPS redirect:

     root@ubuntu-host# curl -I http://localhost
     HTTP/1.1 301 Moved Permanently
     Location: https://localhost/
     Server: nginx/1.18.0 (Ubuntu)


   • Serving content over HTTPS:

     root@ubuntu-host# curl -I https://localhost --insecure
     HTTP/1.1 200 OK
     Server: nginx/1.18.0 (Ubuntu)


All HTTP requests on port 80 now automatically redirect to HTTPS on port 443, ensuring encrypted connections.
