Hello everyone.
A presentation slide titled "Kagent Installation" with a dark curved shape on the right containing the word "Demo." A small "© Copyright KodeKloud" appears in the bottom-left corner.
Welcome to this lesson. Here you’ll learn two ways to install kagent on Kubernetes:
  • Using the kagent CLI installer, and
  • Using Helm charts (recommended for cluster-managed installations).
Objective: be able to install and uninstall kagent with either method and choose the best approach for your environment.

​
Prerequisites

  • A Kubernetes cluster and kubectl configured to target it.
  • Helm installed if you plan to use the Helm method.
  • An LLM provider API key (the examples below use OpenAI). Export your OpenAI key into the environment so the installer can pick it up automatically.
Make sure your OPENAI_API_KEY is set in the environment before installing kagent. You can export it like:
export OPENAI_API_KEY="sk-..."
Verify the environment variable is set:
# Verify the key is available in the environment
echo $OPENAI_API_KEY
# Example output (truncated for security):
# sk-kkAI-7f4db864d4a30df42264af74c22f4f1c5bf51...

​
Quick comparison

Installation MethodBest forKey command
CLI installerLocal testing, quick installs`curl -fsSL https://raw.githubusercontent.com/kagent-dev/kagent/refs/heads/main/scripts/get-kagentbash`
Helm chartProduction or cluster-managed installshelm install kagent oci://ghcr.io/kagent-dev/kagent/helm/kagent

​
CLI-based installation

Follow these steps to install kagent using the kagent CLI installer.
  1. Install the kagent CLI (the installer fetches the latest stable binary):
curl -fsSL https://raw.githubusercontent.com/kagent-dev/kagent/refs/heads/main/scripts/get-kagent | bash
Example installer output:
Downloading https://cr.kagent.dev/v0.7.7/kagent-linux-amd64
Verifying checksum... Done.
Preparing to install kagent into /usr/local/bin
kagent installed into /usr/local/bin/kagent
  1. Confirm the installed kagent version:
kagent version
Example output:
{"backend_version":"unknown","build_date":"2025-12-11","git_commit":"bfe15ba","kagent_version":"0.7.7"}
  1. Inspect available CLI commands and flags:
kagent --help
Trimmed sample output (top-level commands and flags):
kagent is a CLI and TUI for kagent

Usage:
  kagent [flags]
  kagent [command]

Available Commands:
  add-mcp        Add an MCP server entry to kagent.yaml
  bug-report     Generate a bug report
  build          Build a Docker images for an agent project
  completion     Generate the autocompletion script for the specified shell
  dashboard      Open the kagent dashboard
  deploy         Deploy an agent to Kubernetes
  get            Get a kagent resource
  help           Help about any command
  init           Initialize a new agent project
  install        Install kagent
  invoke         Invoke a kagent agent
  mcp            MCP (Model Context Protocol) server management
  run            Run agent project locally with docker-compose and launch chat interface
  uninstall      Uninstall kagent
  version        Print the kagent version

Flags:
      --config string           config file (default is $HOME/.kagent/config.yaml)
  -h, --help                    help for kagent
      --kagent-url string       KAgent URL (default "http://localhost:8083")
  -n, --namespace string        Namespace (default "kagent")
  -o, --output-format string    Output format (default "table")
      --timeout duration        Timeout (default 5m0s)
  -v, --verbose                 Verbose output
  1. Ensure the kagent namespace exists (this creates it if absent):
kubectl create namespace kagent --dry-run=client -o yaml | kubectl apply -f -
  1. Install kagent into the kagent namespace. The installer will use the OPENAI_API_KEY environment variable (no additional flag required for the key):
kagent install -n kagent
Example confirmation:
kagent installed successfully
  1. Verify the deployed pods in the kagent namespace:
kubectl get pods -n kagent
Example output (trimmed):
NAME                                                   READY   STATUS    RESTARTS   AGE
argo-rollouts-conversion-agent-6b75f48f84-skzsc        1/1     Running   0          40s
cilium-debug-agent-5c7798b559-9bbzh                    1/1     Running   0          40s
cilium-manager-agent-5dc4964899-2vkn4                  0/1     Running   0          40s
helm-agent-66d7fd5fb8-dvbr6                            0/1     Running   0          40s
kagent-controller-6886fc4f5c-wn2xm                     1/1     Running   0          97s
kagent-grafana-mcp-5cc85fd598-hw6bk                    1/1     Running   0          97s
kagent-kmcp-controller-manager-76645f577f-n2r5v        1/1     Running   0          97s
kagent-querydoc-5f6fd94c98-64kxn                       1/1     Running   0          97s
kagent-tools-56c49d7d4d-6h8zg                          1/1     Running   0          97s
kagent-ui-59d5bbd564-r7j5q                             1/1     Running   0          97s
kgateway-agent-d97c5f7d-5qg2c                          0/1     Running   0          40s
observability-agent-55d64bd489-987hm                   1/1     Running   0          40s
promql-agent-56c56b98bd-xvlzw                          0/1     Running   0          39s

​
Uninstalling kagent (CLI)

To remove the kagent installation created via the CLI:
kagent uninstall -n kagent
Example output:
Warning: kagent release not found, skipping uninstallation
Warning: kagent-crds release not found, try to delete crds directly
Successfully deleted CRD agents.kagent.dev
Successfully deleted CRD modelconfigs.kagent.dev
Successfully deleted CRD toolservers.kagent.dev

kagent uninstalled successfully

​
Helm-based installation

Helm is a common method for installing kagent in production environments. The recommended sequence is: install CRDs first, then install the application Helm chart.
  1. Install the kagent CRDs from the public Helm OCI chart:
helm install kagent-crds oci://ghcr.io/kagent-dev/kagent/helm/kagent-crds \
  --namespace kagent \
  --create-namespace
Example output (trimmed):
Pulled: ghcr.io/kagent-dev/kagent/helm/kagent-crds:0.7.7
Digest: sha256:9e3a92d7636bf1485fb1de984d579543fd7c1bb8dc57312401e462edc209df91
I1215 09:13:10.543041 47158 warnings.go:110] "Warning: unrecognized format \"int64\""
NAME: kagent-crds
LAST DEPLOYED: Mon Dec 15 09:13:10 2025
NAMESPACE: kagent
STATUS: deployed
REVISION: 1
  1. Verify the CRDs are present:
kubectl get crd | grep kagent
Example output:
agents.kagent.dev                      2025-12-15T09:13:10Z
mcpservers.kagent.dev                  2025-12-15T09:13:10Z
memories.kagent.dev                    2025-12-15T09:13:10Z
modelconfigs.kagent.dev                2025-12-15T09:13:10Z
remotemcpservers.kagent.dev            2025-12-15T09:13:10Z
toolservers.kagent.dev                 2025-12-15T09:13:10Z
  1. Install the kagent Helm chart. Pass the OpenAI API key via Helm values so components can use it. The exact value key name may vary by chart — one common pattern is openai.apiKey. Replace with the correct key for your chart if different:
helm install kagent oci://ghcr.io/kagent-dev/kagent/helm/kagent \
  --namespace kagent \
  --set openai.apiKey="$OPENAI_API_KEY"
  1. Verify Helm releases:
helm list -n kagent
Example output:
NAME        NAMESPACE   REVISION   UPDATED                                 STATUS    CHART                 APP VERSION
kagent      kagent      1          2025-12-15 09:14:04.750303641 +0000 UTC deployed  kagent-0.7.7
kagent-crds kagent      1          2025-12-15 09:13:10.339038232 +0000 UTC deployed  kagent-crds-0.7.7
  1. Confirm services and pods are running:
kubectl get svc -n kagent
kubectl get pods -n kagent
Example services (trimmed):
service/kagent-controller                  8083/TCP
service/kagent-grafana-mcp                8000/TCP
service/kagent-querydoc                   8080/TCP
service/kagent-tools                      8084/TCP
service/kagent-ui                         8080/TCP
service/kgateway-agent                    8080/TCP
service/observability-agent               8080/TCP
service/promql-agent                      8080/TCP
When removing kagent, uninstall the application release first and remove CRDs separately. Deleting CRDs before removing dependent resources can leave orphaned resources or break uninstall workflows.

​
Uninstalling Helm release and CRDs

  1. Uninstall the kagent release:
helm uninstall kagent -n kagent
Example output:
release "kagent" uninstalled
  1. Uninstall the CRDs Helm release:
helm uninstall kagent-crds -n kagent
Example output:
release "kagent-crds" uninstalled
  1. Confirm the namespace no longer contains kagent resources:
kubectl get pods -n kagent
Example output:
No resources found in kagent namespace.

​
Conclusion

This lesson covered how to install and uninstall kagent using:
  • the kagent CLI (quick installer + kagent install), and
  • Helm charts (install CRDs first, then the application chart).
Choose CLI for quick experimentation and Helm for production/cluster-managed deployments. After installation, you can explore the kagent UI, interact with deployed agents, and configure providers via the kagent configuration.
