Hello everyone.
A presentation slide titled "Deploying MCP Server KMCP Way" with the word "Demo" on a dark curved design element to the right. The slide also shows a small "© Copyright KodeKloud" notice in the corner.
Welcome to this hands-on lab. In this lesson we’ll scaffold a Python-based MCP server using the kmcp CLI. The example MCP server will fetch real-time cryptocurrency prices and expose that functionality as MCP tools that agents can call. High-level flow:
  • An agent requests a tool (for example, “get Bitcoin price”).
  • The agent calls the MCP server’s tool endpoints.
  • The MCP server executes the tool code (fetches live price), processes the response, and returns it.
  • KMCP helps scaffold the project, run locally with the Inspector, build a container image, and deploy the MCP server to Kubernetes.
KMCP is the CLI for building and managing Model Context Protocol (MCP) servers. Do not confuse it with the KAgent CLI — KAgent CLI focuses on building and interacting with agents, while KMCP focuses on MCP server tooling, scaffolding, local debugging, builds, and deployments.

​
Install KMCP CLI and MCP Inspector

Install the MCP Inspector (GUI for testing/debugging) and the kmcp CLI.
# Install MCP Inspector (visual debugging)
npm install -g @modelcontextprotocol/inspector

# Install kmcp CLI (official install script from GitHub)
curl -fsSL https://raw.githubusercontent.com/kagent-dev/kmcp/refs/heads/main/scripts/get-kmcp.sh | bash

# Verify kmcp installation
kmcp --version
Example console output after installation:
Downloading https://github.com/kagent-dev/kmcp/releases/download/v0.2.2/kmcp-linux-amd64
Preparing to install kmcp into /usr/local/bin
kmcp installed into /usr/local/bin/kmcp

🎉 KMCP installation completed successfully!
To verify the installation, please run:
kmcp --version

controlplane ~ ➜ kmcp --version
kmcp version 0.2.2
To explore kmcp commands:
kmcp --help
Abbreviated sample output:
KMCP is a CLI tool for building and managing Model Context Protocol (MCP) servers.

Usage:
  kmcp [flags]

Available Commands:
  add-tool     Add a new MCP tool to your project
  build        Build MCP server as a Docker image
  deploy       Deploy MCP server to Kubernetes
  init         Initialize a new MCP server project
  install      Install the KMCP controller on a Kubernetes cluster
  run          Run MCP server locally
  secrets      Manage project secrets
  help         Help about any command

​
Initialize a Python MCP Project

Create a new Python MCP scaffold:
kmcp init python crypto-price-mcp
Sample output:
To run the server locally:
  kmcp run local --project-dir /root/crypto-price-mcp
✓ Successfully created Python MCP server project: crypto-price-mcp
View the generated project structure:
ls -ltr crypto-price-mcp
Example listing:
total 28
drwxr-xr-x 2 root root 4096 Dec 19 07:38 tests
drwxr-xr-x 4 root root 4096 Dec 19 07:38 src
-rw-r--r-- 1 root root 4918 Dec 19 07:38 README.md
-rw-r--r-- 1 root root 1042 Dec 19 07:38 pyproject.toml
-rw-r--r-- 1 root root 1824 Dec 19 07:38 Dockerfile
-rw-r--r-- 1 root root 586 Dec 19 07:38 kmcp.yaml

​
Project Key Files

Below is a quick reference to the key files generated by kmcp init:
FilePurposeExample / Notes
kmcp.yamlMain MCP configuration (environments, secrets, metadata)See example YAML below
pyproject.tomlPython packaging and dependency configurationUse dependency-groups for dev dependencies
DockerfileImage build instructions for containerizationUsed by kmcp build
src/Source code: core server and toolssrc/main.py, src/tools/*
Example kmcp.yaml (abbreviated):
name: crypto-price-mcp
framework: fastmcp-python
version: 0.1.0
description: MCP server built with fastmcp-python
secrets:
  local:
    enabled: false
    provider: env
    file: .env.local
  production:
    enabled: false
    provider: kubernetes
    secretName: crypto-price-mcp-secrets-production
    namespace: default
created_at: 2025-12-19T07:38:32.303583657Z
updated_at: 2025-12-19T07:38:32.338228897Z
Do not commit sensitive keys or API secrets to version control. Use kmcp secrets with a secrets provider (env files or Kubernetes Secrets) and reference them from kmcp.yaml so your tools can read them securely at runtime.

​
Inspecting src/main.py

The generated src/main.py boots the FastMCP server and registers tools. It typically parses CLI arguments for transport and host/port, then starts the server. Representative excerpt:
# src/main.py
import argparse
import sys
from pathlib import Path

# Add src to Python path
sys.path.insert(0, str(Path(__file__).parent))

from core.server import DynamicMCPServer  # noqa: E402

def main() -> None:
    """Main entry point for the MCP server."""
    parser = argparse.ArgumentParser(description="crypto-price-mcp MCP Server")
    parser.add_argument("--transport", choices=["stdio", "http"], default="stdio",
                        help="Transport mode: stdio or http")
    parser.add_argument("--host", default="127.0.0.1", help="Host for HTTP transport")
    parser.add_argument("--port", type=int, default=8080, help="Port for HTTP transport")
    args = parser.parse_args()

    server = DynamicMCPServer(project_dir=Path(__file__).parent)
    server.run(transport=args.transport, host=args.host, port=args.port)

if __name__ == "__main__":
    main()
Notes:
  • DynamicMCPServer loads tools from src/tools and exposes them over the chosen transport.
  • Use --transport http for running as an HTTP service (suitable for Kubernetes), or stdio for Inspector/local development.

​
Tools: Example echo tool

Tools live under src/tools. Each tool is a Python function decorated with @mcp.tool() so the MCP server can register it and expose metadata. Example src/tools/echo.py:
# src/tools/echo.py
"""Example echo tool for crypto-price-mcp MCP server."""

from core.server import mcp
from core.utils import get_tool_config

@mcp.tool()
def echo(message: str) -> str:
    """Echo a message back to the client.

    Args:
        message: The message to echo

    Returns:
        The echoed message with any configured prefix
    """
    config = get_tool_config("echo")
    prefix = config.get("prefix", "")
    return f"{prefix}{message}" if prefix else message
Tool definition tips:
  • @mcp.tool() registers the function as a callable MCP tool.
  • Type annotations help schema generation for inputs/outputs.
  • Docstrings are surfaced in the Inspector UI as descriptions.
  • Use core.utils.get_tool_config to read tool-specific configuration from kmcp.yaml.

​
Add a New Tool and Run Locally

Add a new tool scaffold to your project:
kmcp add-tool my_tool --project-dir ./crypto-price-mcp
Run the MCP server locally. The kmcp run command installs dependencies and starts the MCP Inspector proxy for local debugging:
kmcp run --project-dir ./crypto-price-mcp
Example output when starting:
warning: The `tool.uv.dev-dependencies` field (used in pyproject.toml) is deprecated; use `dependency-groups.dev` instead
Resolved 104 packages
Starting MCP inspector...
⚙ Proxy server listening on 127.0.0.1:6277
🔑 Session token: 46f50eb8951e5e501c94fffdec7a4dd39a1973a4c05c737e2e32e76aeed590a3
Use this token to authenticate requests

🔗 Open inspector with token pre-filled:
http://localhost:6274/?MCP_PROXY_AUTH_TOKEN=46f50eb8951e5e501c94fffdec7a4dd39a1973a4c05c737e2e32e76aeed590a3

🟢 MCP Inspector is up and running at http://127.0.0.1:6274 🚀

​
MCP Inspector — Visual Debugging and Testing

MCP Inspector is a Postman-like UI for exploring and invoking tools exposed by an MCP server. It proxies connections to the running server and displays tools, schemas, and responses. Example inspector startup output:
Starting MCP inspector...
Proxy server listening on 127.0.0.1:6277
Session token: d2e3a6e837cd46fbd3bf344186d490d9fb1e0808e0b9a6554afcd49fb5d8f04a

Open inspector with token pre-filled:
http://localhost:6274/?MCP_PROXY_AUTH_TOKEN=d2e3a6e837cd46fbd3bf344186d490d9fb1e0808e0b9a6554afcd49fb5d8f04a

MCP Inspector is up and running at http://127.0.0.1:6274 🚀
Connection details saved to: /root/mcp-inspector-info.txt

​
Connecting the Inspector to the MCP Server

In the Inspector UI, configure the connection:
  • Transport Type: STDIO
  • Command: uv (the uv entrypoint used in the generated project)
  • Arguments: run python /root/crypto-price-mcp/src/main.py
Example inspector connection command shown in the UI:
Command: uv
Arguments: run python /root/crypto-price-mcp/src/main.py
Provide the Inspector Proxy Address and Session Token (from the start output) and click Connect. When connected you’ll see a green indicator and can list and invoke tools.

​
Listing and Running Tools in Inspector

The Inspector lists available tools and their input/output schemas. For the scaffolded project you’ll see the echo tool. Inspector tools listing example:
Tools
List Tools

echo
Echo a message back to the client.
Args: message: The message to echo
Returns: The echoed message with any configured prefix
Run the echo tool by providing input and clicking Run. Example response shown by Inspector:
{
  "result": "hello how are you today ?"
}
Under the hood: the Inspector sends an MCP request to the server; the server validates and dispatches to the registered tool function; the tool runs, and the server returns an MCP-compliant response the Inspector displays.

​
Build and Deploy (Overview)

Once your tools are ready, build a Docker image and deploy to Kubernetes:
# Build Docker image (tag as required)
kmcp build --project-dir ./crypto-price-mcp -t myregistry/crypto-price-mcp:latest

# Deploy using the generated kmcp.yaml and image
kmcp deploy --file crypto-price-mcp/kmcp.yaml --image myregistry/crypto-price-mcp:latest
Explore kmcp --help for command options for init, add-tool, run, build, deploy, install, and secrets management.

​
Next Steps / Recommendations

  • Implement a real crypto pricing tool under src/tools/ that calls a public API for BTC/ETH prices.
  • Store API keys and secrets via kmcp.yaml and a secrets provider; fetch them in tools with core.utils.get_tool_config.
  • Iterate rapidly using MCP Inspector during development to validate tool schemas and responses.
  • When satisfied, run kmcp build to produce an image and kmcp deploy to push to Kubernetes.
  • Read the KMCP repository and docs for advanced deployment options and controllers.
Links and references: Good luck building your custom MCP server!
