Demo Zero Downtime Canary Deployment

In this hands‑on demo you’ll learn how to perform a zero‑downtime canary (progressive) rollout using the Gateway API. We use the NGINX Gateway implementation for the demo, but the Gateway API resources and concepts apply across implementations (for example HAProxy).

A presentation slide titled "Zero-Downtime Canary Deployment" with a large turquoise curved shape on the right that says "Demo." The slide also shows a small copyright notice for KodeKloud in the corner.

Overview

Deploy two versions of the same application: coffee (v1) and coffeev2 (v2).
Create an HTTPRoute attached to the Gateway that splits traffic between the two Services using weight to simulate canary rollouts.
Drive requests to the route and observe how the Gateway distributes traffic as you change weights.

Why use Gateway API for canaries?

Gateway API provides first‑class routing primitives (HTTPRoute, TCPRoute, etc.) that support weighted backend splitting.
Weighted routing enables gradual rollouts without changing client endpoints — zero downtime and safer deployments.

Initial cluster state (before starting)

Only v1 (coffee) is running and no HTTPRoute exists yet. The gateway is already deployed.

Example checks (initial):

# No HTTPRoute yet
kubectl get httproute
# Pods currently running (example output)
kubectl get pods
# NAME                                READY   STATUS    RESTARTS   AGE
# coffee-5b9c74f9d9-9rf2f             1/1     Running   0          138m
# gateway-nginx-5f9d4c4ff-2d7zp       1/1     Running   0          136m

Quick reference: Kubernetes resources used

Resource Type	Purpose	Example
Deployment	Run application replicas	`kubectl apply -f coffeev2-app.yaml`
Service	Expose pods to other cluster components	`service/coffeev2`
HTTPRoute	Attach host/path routing and weight-based backend traffic splits to a Gateway	`httproute.gateway.networking.k8s.io/splitroute`
Gateway (existing)	Entry point for external traffic	`gateway` (sectionName: `http`)

Step 1 — Deploy the v2 application Create a Deployment and Service for coffeev2 (v2 of the same app). This manifest uses the same image as v1, exposes port 8080 in the pod and Service port 80. coffeev2-app.yaml:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: coffeev2
  labels:
    app: coffeev2
spec:
  replicas: 1
  selector:
    matchLabels:
      app: coffeev2
  template:
    metadata:
      labels:
        app: coffeev2
    spec:
      containers:
      - name: coffee
        image: nginxdemos/nginx-hello:plain-text
        ports:
        - containerPort: 8080
---
apiVersion: v1
kind: Service
metadata:
  name: coffeev2
spec:
  ports:
  - port: 80
    targetPort: 8080
    protocol: TCP
    name: http
  selector:
    app: coffeev2

Apply the manifest and confirm pods/services:

kubectl apply -f coffeev2-app.yaml
# deployment.apps/coffeev2 created
kubectl get pods
# NAME                                READY   STATUS    RESTARTS   AGE
# coffee-5b9c74f9d9-9rf2f             1/1     Running   0          140m
# coffeev2-6bb54b9bc7-v4wt9           1/1     Running   0          10s
kubectl get svc
# NAME            TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)         AGE
# coffee          ClusterIP   10.96.197.88     <none>        80/TCP          140m
# coffeev2        ClusterIP   10.96.83.74      <none>        80/TCP          8s
# gateway-nginx   NodePort    10.96.56.153     <none>        80:31437/TCP    138m
# kubernetes      ClusterIP   10.96.0.1        <none>        443/TCP         162m

Step 2 — Create an HTTPRoute that splits traffic Create an HTTPRoute named splitroute that attaches to the existing gateway (sectionName http) and splits requests for host cafe.example.com on the /coffee path between two backend Services using weight. Initial canary route (75/25):

apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: splitroute
spec:
  parentRefs:
  - name: gateway
    sectionName: http
  hostnames:
  - "cafe.example.com"
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /coffee
    backendRefs:
    - name: coffee
      port: 80
      weight: 75
    - name: coffeev2
      port: 80
      weight: 25

Apply the route:

kubectl apply -f canary-route.yaml
kubectl get httproute
# NAME       HOSTNAMES                 AGE
# splitroute ["cafe.example.com"]      38s

Testing traffic splitting

Use curl with --resolve to send requests to the gateway address while setting the Host header to cafe.example.com. In these examples we use localhost:8080. If your Gateway is exposed as a NodePort (e.g., 31437) or you prefer to port-forward, update the port accordingly.
The app response includes Server name (pod name) and Server address so you can identify which backend served each request.

Tip: ensure the gateway is reachable on the chosen port and that DNS Host header is set via --resolve.

If your Gateway is exposed on a NodePort (for example 31437) or through a load balancer, replace 8080 in the examples with the Gateway’s listening port, or use kubectl port-forward to map the gateway to localhost:8080.

Representative requests with initial weights (mostly v1):

curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee
# Server address: 10.244.0.7:8080
# Server name: coffee-5b9c74f9d9-9rf2f
# Date: 11/Apr/2026:22:16:10 +0000
# URI: /coffee
curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee
# Server address: 10.244.0.7:8080
# Server name: coffee-5b9c74f9d9-9rf2f
curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee
# Server address: 10.244.0.7:8080
# Server name: coffee-5b9c74f9d9-9rf2f
curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee
# Server address: 10.244.0.12:8080
# Server name: coffeev2-6bb54b9bc7-v4wt9
# Request ID: c01682b0a71c65bd6a2bc129b655ec4b

Weighted traffic splitting is probabilistic: a 75/25 weight is an approximate distribution. With a small sample of requests you may see variance; the distribution converges with higher request volume.

Step 3 — Adjust weights to simulate a progressive rollout Update the HTTPRoute weights to gradually shift traffic toward coffeev2. Each change is a single manifest edit and kubectl apply. Example: change weights to 90/10

# Edit canary-route.yaml: set coffee weight to 90, coffeev2 weight to 10
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: splitroute
spec:
  parentRefs:
  - name: gateway
    sectionName: http
  hostnames:
  - "cafe.example.com"
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /coffee
    backendRefs:
    - name: coffee
      port: 80
      weight: 90
    - name: coffeev2
      port: 80
      weight: 10

Apply the change:

kubectl apply -f canary-route.yaml
# httproute.gateway.networking.k8s.io/splitroute configured

Example: change to 50/50 (even split)

apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: splitroute
spec:
  parentRefs:
  - name: gateway
    sectionName: http
  hostnames:
  - "cafe.example.com"
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /coffee
    backendRefs:
    - name: coffee
      port: 80
      weight: 50
    - name: coffeev2
      port: 80
      weight: 50

Apply and test (repeat curl requests). You should see a more even distribution. Representative 50/50 sequence:

curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee
curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee
curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee
curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee
# Server name: coffeev2-6bb54b9bc7-v4wt9

Step 4 — Promote v2 to 100% (complete cutover) When coffeev2 is validated and healthy, update the route so all traffic goes to v2 and v1 receives none. Final route for 0/100:

apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: splitroute
spec:
  parentRefs:
  - name: gateway
    sectionName: http
  hostnames:
  - "cafe.example.com"
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /coffee
    backendRefs:
    - name: coffee
      port: 80
      weight: 0
    - name: coffeev2
      port: 80
      weight: 100

Apply and verify:

kubectl apply -f canary-route.yaml
# Now all requests should land on coffeev2
curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee
# Server name: coffeev2-6bb54b9bc7-v4wt9

Best practices for safe canary rollouts

Start small: begin with a low percentage (for example 1% → 5% → 25%) and increase as confidence grows.
Monitor errors, latency, logs, and business metrics continuously during each step.
Automate and track changes via GitOps (ArgoCD, FluxCD) for auditable rollouts and easy rollbacks.
Remember weights are probabilistic. For precision testing use a sufficiently large request volume or a traffic generator.
Consider session affinity or consistent hashing if your app requires sticky sessions during canaries.

Links and references

Gateway API specification: https://gateway-api.sigs.k8s.io/
NGINX Gateway documentation: https://www.nginx.com/products/nginx-kubernetes-gateway/
Kubernetes documentation: https://kubernetes.io/docs/
GitOps with ArgoCD: https://argoproj.github.io/argo-cd/
FluxCD: https://fluxcd.io/

That’s it — you now have a practical zero‑downtime canary demo using Gateway API and the NGINX Gateway.
