Demo Multi Service Application Gateway

Welcome to demo two. In this walkthrough we take the first steps with the Gateway API and the NGINX Fabric Gateway implementation. You’ll deploy a simple app, expose it with a Kubernetes Service, create a Gateway that accepts *.example.com, and attach an HTTPRoute so external requests reach the app.

A presentation slide reading "Multi-Service Application Gateway" on the left and a large turquoise shape on the right with the word "Demo." A small "© Copyright KodeKloud" label appears in the bottom-left.

Application and Service

This demo uses a simple “coffee” application deployed as a Deployment and exposed via a ClusterIP Service named coffee. Key Service details:

Service name: coffee
Service port: 80
Target container port: 8080
Protocol: TCP
Service port name: http

Verify the Deployment and Service:

kubectl get deployments
kubectl get services

Gateway manifest

Create a Gateway to accept HTTP on port 80. The Gateway references a GatewayClass (nginx) so the underlying implementation (control plane + data plane) knows which controller to use. The listener restricts hostnames to *.example.com, allowing routes to match subdomains such as cafe.example.com.

# gateway.yaml
apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
  name: gateway
spec:
  gatewayClassName: nginx
  listeners:
  - name: http
    port: 80
    protocol: HTTP
    hostname: "*.example.com"

Apply the Gateway and inspect status:

kubectl apply -f gateway.yaml
kubectl get gateway
kubectl get pods

Example terminal output after creating the Gateway:

$ kubectl apply -f gateway.yaml
gateway.gateway.networking.k8s.io/gateway created

$ kubectl get gateway
NAME      CLASS   ADDRESS        PROGRAMMED   AGE
gateway   nginx   10.96.56.153   True         10s

$ kubectl get pods
NAME                               READY   STATUS    RESTARTS   AGE
coffee-5b9c74f9d9-9rf2f            1/1     Running   0          3m
gateway-nginx-5f9d4c4ff-2d7zp      0/1     Running   0          20s

When the Gateway is created, the implementation spins up a data-plane pod (for example gateway-nginx-...) that receives translated configuration from the Gateway API control plane. Wait for that pod to reach Running before testing.

The Gateway’s hostname (for example *.example.com) limits which Host header / SNI values are accepted. Routes (HTTPRoute) that target a specific hostname like cafe.example.com must match a hostname allowed by the Gateway.

HTTPRoute manifest

Create an HTTPRoute that binds to the gateway listener (section http) and routes requests with the /coffee path prefix to the coffee Service on port 80.

# coffee-route.yaml
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: coffee
spec:
  parentRefs:
  - name: gateway
    sectionName: http
  hostnames:
  - "cafe.example.com"
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /coffee
    backendRefs:
    - name: coffee
      port: 80

Apply the HTTPRoute and verify the configured resources:

kubectl apply -f coffee-route.yaml
kubectl get httproute
kubectl get gateway
kubectl get pods
kubectl get svc

Example terminal output:

$ kubectl apply -f coffee-route.yaml
httproute.gateway.networking.k8s.io/coffee created

$ kubectl get httproute
NAME     HOSTNAMES             AGE
coffee   ["cafe.example.com"]  12s

$ kubectl get gateway
NAME     CLASS   ADDRESS       PROGRAMMED  AGE
gateway  nginx   10.96.56.153  True        2m30s

$ kubectl get pods
NAME                               READY   STATUS    RESTARTS   AGE
coffee-5b9c74f9d9-9rf2f            1/1     Running   0          5m
gateway-nginx-5f9d4c4ff-2d7zp      1/1     Running   0          3m

$ kubectl get svc
NAME           TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)         AGE
coffee         ClusterIP   10.96.197.88   <none>        80/TCP           5m
gateway-nginx  NodePort    10.96.56.153   <none>        80:31437/TCP     3m
kubernetes     ClusterIP   10.96.0.1      <none>        443/TCP          26m

Testing with curl

In a local lab environment we often don’t have real DNS for cafe.example.com, so we use curl --resolve to override DNS and send the correct Host header. You can reach the Gateway either by port-forwarding the Gateway service to localhost or by hitting the NodePort exposed by the Gateway. Port-forward example (forward service port 80 to local 8080):

kubectl port-forward svc/gateway-nginx 8080:80

Then request the /coffee path while preserving the Host header:

curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee

Alternatively, target the NodePort shown in kubectl get svc (31437 in the example):

curl --resolve cafe.example.com:31437:127.0.0.1 http://cafe.example.com:31437/coffee

The Gateway implementation will accept the Host header cafe.example.com and route /coffee to the coffee Service. Successful request example (same curl command as above):

curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee

Example response body returned by the coffee application (fields vary by app):

Server address: 10.244.0.7:8080
Server name: coffee-5b9c74f9d9-9rf2f
Date: 11/Apr/2026:19:58:03 +0000
URI: /coffee
Request ID: 6af36e55-15ba-1173-5d84-b62a58833a5b

If you request a path that does not match any configured route (for example /coffee123), the Gateway proxy returns a 404:

curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee123

Example 404 response from the proxy (NGINX):

<html>
<head><title>404 Not Found</title></head>
<body>
<center><h1>404 Not Found</h1></center>
<hr><center>nginx</center>
</body>
</html>

Quick resource summary

Resource	Purpose	Example / Command
Deployment	Runs the coffee app	`kubectl get deployments`
Service (ClusterIP)	Internal service for pods	`name: coffee`, `port: 80 -> targetPort: 8080`
Gateway	Listens for external traffic, implemented by `GatewayClass`	`gateway.yaml` (above)
HTTPRoute	Routes requests (host + path) to backends	`coffee-route.yaml` (above)
Test access	Local testing using Host header override	`curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee`

Summary

Deployed the coffee application and exposed it via a ClusterIP Service.
Created a Gateway that listens on HTTP port 80 and accepts *.example.com.
Attached an HTTPRoute for cafe.example.com and routed /coffee requests to the coffee Service.
Tested end-to-end routing locally with curl --resolve (or via NodePort / port-forward).

References

Gateway API: https://gateway-api.sigs.k8s.io/
Kubernetes documentation: https://kubernetes.io/docs/
NGINX documentation: https://docs.nginx.com/
