Demo Configure TLS with Auto Redirect

In this lesson you will learn how to terminate TLS at a Gateway using a Kubernetes Secret, configure an HTTP→HTTPS redirect, and allow cross-namespace Secret references using a ReferenceGrant. We use a self-signed certificate for the lab so you can test HTTPS locally.

A presentation slide titled "Configure TLS with Auto-Redirect" with a large blue teardrop-shaped area on the right containing the word "Demo." The slide has a clean white background and a small copyright notice for KodeKloud.

Environment status

At the start of the lab only the coffee application and its Service are running — no Gateways or HTTPRoutes are present.

# pods
~/coding/kubernetes/nginx-fabric-gateway/kodekloud/lab-3-tls
> kubectl get po
NAME                       READY   STATUS    RESTARTS   AGE
coffee-5b9c74f9d9-9rf2f    1/1     Running   0          3h15m

What we’ll deploy

A Gateway (in default) with:
- HTTP listener on port 80
- HTTPS listener on port 443 with TLS termination using a Secret
Two HTTPRoutes:
- One on the HTTP listener that redirects requests to HTTPS (301)
- One on the HTTPS listener that forwards /coffee to the coffee Service
A certificate namespace with a TLS Secret cafe-secret (self-signed)
A ReferenceGrant that allows the Gateway in default to reference the Secret in certificate

Files in the working directory:

~/coding/kubernetes/nginx-fabric-gateway/kodekloud/lab-3-tls
> ls
cert.yaml                    coffee-redirect-route.yaml   gateway.yaml
coffee-https-only-route.yaml coffee-rewrite-route.yaml    ns.yaml
ref-grant.yaml               routes.yaml

Quick reference — manifests and purpose

Manifest	Resource(s)	Purpose
`ns.yaml`	Namespace	Creates the `certificate` namespace
`cert.yaml`	`Secret` (`kubernetes.io/tls`)	Self-signed TLS cert stored as `cafe-secret` in `certificate`
`ref-grant.yaml`	`ReferenceGrant`	Allows Gateway in `default` to reference `certificate/cafe-secret`
`gateway.yaml`	`Gateway`	HTTP and HTTPS listeners, TLS terminate mode, references `cafe-secret`
`routes.yaml`	`HTTPRoute`s	HTTP->HTTPS redirect and `/coffee` backend route

Relevant docs:

Gateway API overview: https://gateway-api.sigs.k8s.io/
ReferenceGrant: https://gateway-api.sigs.k8s.io/spec/#referencegrant

Gateway manifest (gateway.yaml)

This Gateway uses the nginx GatewayClass and terminates TLS using a Secret in the certificate namespace.

apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
  name: gateway
spec:
  gatewayClassName: nginx
  listeners:
  - name: http
    port: 80
    protocol: HTTP
    hostname: "*.example.com"
  - name: https
    port: 443
    hostname: "*.example.com"
    protocol: HTTPS
    tls:
      mode: Terminate
      certificateRefs:
      - kind: Secret
        name: cafe-secret
        namespace: certificate
  allowedRoutes:
    namespaces:
      from: All

Notes on TLS mode

Terminate means TLS is terminated at the Gateway; traffic to backend pods will be plain HTTP.
Because the Secret is in a different namespace (certificate) than the Gateway (default), a ReferenceGrant is required to allow cross-namespace references.

Namespace and Secret (ns.yaml & cert.yaml)

ns.yaml creates the certificate namespace.
cert.yaml contains the kube TLS Secret cafe-secret with base64-encoded tls.crt and tls.key (self-signed for lab/testing).

Example namespace:

apiVersion: v1
kind: Namespace
metadata:
  name: certificate

Example Secret (cert.yaml excerpt):

apiVersion: v1
kind: Secret
metadata:
  name: cafe-secret
  namespace: certificate
type: kubernetes.io/tls
data:
  tls.crt: LS0tLS1CRUdJTiBDRVJUSUZJQ0FURS0tLS0tCk1JSURq...  # base64-encoded cert
  tls.key: LS0tLS1CRUdJTiBSU0EgUFJJVkFURSBLRVktLS0tLS0K...  # base64-encoded key

Apply namespace and Secret:

~/coding/kubernetes/nginx-fabric-gateway/kodekloud/lab-3-tls
> kubectl apply -f ns.yaml
namespace/certificate created

> kubectl apply -f cert.yaml
secret/cafe-secret created

ReferenceGrant (ref-grant.yaml)

A ReferenceGrant in the certificate namespace grants permission for Gateways in default to use the Secret.

apiVersion: gateway.networking.k8s.io/v1beta1
kind: ReferenceGrant
metadata:
  name: access-certificate
  namespace: certificate
spec:
  to:
  - group: ""
    kind: Secret
    name: cafe-secret
  from:
  - group: gateway.networking.k8s.io
    kind: Gateway
    namespace: default

Apply the ReferenceGrant:

> kubectl apply -f ref-grant.yaml
referencegrant.gateway.networking.k8s.io/access-certificate created

Create the Gateway

> kubectl apply -f gateway.yaml
gateway.gateway.networking.k8s.io/gateway created

> kubectl get gateway
NAME      CLASS   ADDRESS        PROGRAMMED   AGE
gateway   nginx   10.96.124.112  True         6s

HTTPRoutes (routes.yaml)

We create two HTTPRoute resources:

cafe-tls-redirect — attached to the Gateway’s HTTP listener; issues a 301 redirect to HTTPS.
coffee — attached to the Gateway’s HTTPS listener; matches path prefix /coffee and forwards requests to the coffee Service on port 80.

kind: HTTPRoute
apiVersion: gateway.networking.k8s.io/v1
metadata:
  name: cafe-tls-redirect
spec:
  parentRefs:
  - name: gateway
    sectionName: http
  hostnames:
  - "cafe.example.com"
  rules:
  - filters:
    - type: RequestRedirect
      requestRedirect:
        scheme: https
        port: 443
        statusCode: 301
---
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: coffee
spec:
  parentRefs:
  - name: gateway
    sectionName: https
  hostnames:
  - "cafe.example.com"
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /coffee
    backendRefs:
    - name: coffee
      port: 80

Apply the routes:

> kubectl apply -f routes.yaml
httproute.gateway.networking.k8s.io/cafe-tls-redirect created
httproute.gateway.networking.k8s.io/coffee created

Verify resources

Check the Secret, ReferenceGrant, and HTTPRoutes:

# secret in the certificate namespace
> kubectl get secret -n certificate
NAME          TYPE                DATA   AGE
cafe-secret   kubernetes.io/tls   2      10s

# ReferenceGrant in the certificate namespace
> kubectl get referencegrant -n certificate
NAME                 AGE
access-certificate   10s

# list HTTPRoutes
> kubectl get httproutes
NAME               AGE
cafe-tls-redirect  20s
coffee             20s

Testing behavior with curl

In this lab the Gateway ports are exposed on localhost using mapped ports (example: 8080 for HTTP and 8443 for HTTPS). We use --resolve so cafe.example.com resolves to 127.0.0.1 at the chosen port.

Access HTTP (expect a 301 redirect to HTTPS)

~/coding/kubernetes/nginx-fabric-gateway/kodekloud/lab-3-tls
> curl --resolve cafe.example.com:8080:127.0.0.1 http://cafe.example.com:8080/coffee --include
HTTP/1.1 301 Moved Permanently
Server: nginx
Date: Sat, 11 Apr 2026 23:15:34 GMT
Content-Type: text/html
Content-Length: 162
Connection: keep-alive
Location: https://cafe.example.com/coffee

<html>
<head><title>301 Moved Permanently</title></head>
<body>
<center><h1>301 Moved Permanently</h1></center>
<hr><center>nginx</center>
</body>
</html>

Access HTTPS (Gateway terminates TLS; the cert is self-signed so --insecure is used here)

~/coding/kubernetes/nginx-fabric-gateway/kodekloud/lab-3-tls
> curl --resolve cafe.example.com:8443:127.0.0.1 https://cafe.example.com:8443/coffee --insecure
Server address: 10.244.0.7:8080
Server name: coffee-5b9c74f9d9-9rf2f
Date: 11/Apr/2026:23:18:01 +0000
URI: /coffee
Request ID: 46977f9b19ff33a3535e1c3a252a4599

The HTTPS curl uses --insecure because this lab uses a self-signed certificate. In production, use certificates signed by a trusted CA (for example via Let’s Encrypt or an internal PKI) and proper DNS; you won’t need --resolve or --insecure.

Summary

The Gateway is configured to terminate TLS with a Secret stored in a separate namespace.
A ReferenceGrant allows the Gateway to reference that cross-namespace Secret.
An HTTPRoute on the HTTP listener performs a 301 redirect to HTTPS.
The HTTPS listener forwards /coffee to the coffee backend Service.
For production deployments use a trusted certificate and real DNS so clients can validate TLS without bypassing checks.
