Demo CICD Pipeline Setup

In this lesson we’ll build a simple CI/CD pipeline for a Flask application that generates Wi‑Fi QR codes. The pipeline uses GitHub Actions to run tests and deploy the app to an Ubuntu EC2 instance over SSH whenever changes are merged into main. Goals

Validate code with automated tests (pytest) on PRs and pushes.
On merge to main, deploy the latest code to an Ubuntu EC2 server via SSH.
Keep deployment credentials in GitHub Actions Secrets and automate the server-side deployment with a reusable deploy.sh script and a systemd service.

This guide shows a practical, production-focused example: local development → CI tests in GitHub Actions → SSH deploy to an Ubuntu EC2 instance. Adjust versions and service names to match your environment.

Overview

Application: Flask web app that constructs a Wi‑Fi QR payload and returns a generated QR image.
CI/CD: GitHub Actions runs tests and, on merge to main, SSHes into the EC2 server to pull the latest code and restart services.
Server setup: deploy.sh handles package installation, virtual environment setup, nginx configuration, and creation of a systemd service unit.

Quick file/resource map

Resource	Purpose	Example path / name
Flask app	Generate Wi‑Fi QR payloads and render QR images	`app.py`
Deploy script	Server-side initial setup & one-time tasks	`deploy.sh`
GH Actions workflow	Run tests and trigger remote deploy	`.github/workflows/deploy.yml`
systemd unit	Run Flask app under virtualenv	`/etc/systemd/system/wifi-qr-generator.service`
nginx site config	Reverse proxy to the Flask app	`/etc/nginx/sites-available/wifi-qr-generator`

Application (app.py)

Below is a consolidated, production-friendly core of the Flask application used in the demo. This includes safe escaping for Wi‑Fi QR payload fields and a minimal route that returns a base64-encoded QR image suitable for embedding in templates.

# app.py
from flask import Flask, render_template, request, jsonify
import io
import base64
import qrcode
import os

app = Flask(__name__)

def escape_wifi_text(s: str) -> str:
    """
    Escape special characters per Wi‑Fi QR standard: backslash, semicolon, comma, colon, and quotes.
    """
    if s is None:
        return ""
    s = s.replace("\\", "\\\\")
    s = s.replace(";", r"\;").replace(",", r"\,").replace(":", r"\:")
    s = s.replace("'", r"\'").replace('"', r'\"')
    return s

def build_wifi_payload(ssid: str, password: str, auth: str, hidden: bool) -> str:
    """
    Build the Wi‑Fi QR payload:
    WIFI:T:<auth>;S:<ssid>;P:<password>;H:<hidden>;;
    When auth is "nopass" omit the P: field.
    """
    auth_map = {"WPA/WPA2/WPA3": "WPA", "WEP": "WEP", "None (open)": "nopass"}
    t = auth_map.get(auth, "WPA")
    ssid_e = escape_wifi_text(ssid or "")
    pwd_e = escape_wifi_text(password or "")
    hidden_str = "true" if hidden else "false"

    if t == "nopass":
        payload = f"WIFI:T:{t};S:{ssid_e};H:{hidden_str};;"
    else:
        payload = f"WIFI:T:{t};S:{ssid_e};P:{pwd_e};H:{hidden_str};;"
    return payload

def qr_image_base64(data: str, box_size: int = 10, border: int = 4) -> str:
    qr = qrcode.QRCode(box_size=box_size, border=border)
    qr.add_data(data)
    qr.make(fit=True)
    img = qr.make_image(fill_color="black", back_color="white")
    buffer = io.BytesIO()
    img.save(buffer, format="PNG")
    encoded = base64.b64encode(buffer.getvalue()).decode("ascii")

@app.route("/", methods=["GET"])
def index():
    # Render a simple form (templates/index.html)
    return render_template("index.html")

@app.route("/generate", methods=["POST"])
def generate():
    ssid = request.form.get("ssid", "")
    password = request.form.get("password", "")
    auth = request.form.get("auth", "WPA/WPA2/WPA3")
    hidden = request.form.get("hidden", "false") == "true"

    payload = build_wifi_payload(ssid, password, auth, hidden)
    img_b64 = qr_image_base64(payload)
    return jsonify({"payload": payload, "image": img_b64})

if __name__ == "__main__":
    # Use FLASK_ENV for backward compatibility with older setups, but prefer explicit config.
    debug_mode = os.getenv("FLASK_ENV") == "development" or os.getenv("FLASK_DEBUG") == "1"
    app.run(debug=debug_mode, host="0.0.0.0", port=5001)

Note: In modern Flask versions, FLASK_ENV may be deprecated. Prefer configuring environment variables or a config object (e.g., FLASK_DEBUG) for new projects.

What we want from CI/CD

Run tests (pytest) for pull requests and on push.
On merge to main, connect to the EC2 server via SSH to:
- Pull the latest code
- Create/activate a virtualenv and (re)install dependencies
- Restart the systemd service and reload nginx
Store the EC2 host, user, and private key in repository Secrets in GitHub.

GitHub Actions workflow (example)

This workflow runs tests and, when merged to main, deploys via SSH by executing a remote script block.

# .github/workflows/deploy.yml (excerpt)
name: CI/CD Deploy

on:
  push:
    branches: [ main ]
  pull_request:
    branches: [ main ]

jobs:
  test:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
      - name: Set up Python
        uses: actions/setup-python@v4
        with:
          python-version: '3.11'
      - name: Install dependencies and run tests
        run: |
          python -m pip install --upgrade pip
          pip install -r requirements.txt
          pytest

  deploy:
    needs: test
    runs-on: ubuntu-latest
    if: github.ref == 'refs/heads/main'
    steps:
      - uses: actions/checkout@v4
      - name: Set up Python
        uses: actions/setup-python@v4
        with:
          python-version: '3.11'
      - name: Run tests
        run: |
          python -m pip install --upgrade pip
          pip install -r requirements.txt
          pytest
      - name: Setup SSH key
        run: |
          mkdir -p ~/.ssh
          printf '%s\n' "${{ secrets.EC2_SSH_KEY }}" > ~/.ssh/deploy_key
          chmod 600 ~/.ssh/deploy_key
          ssh-keyscan -H ${{ secrets.EC2_HOST }} >> ~/.ssh/known_hosts
      - name: Test SSH connection
        run: |
          ssh -i ~/.ssh/deploy_key -o StrictHostKeyChecking=no -o ConnectTimeout=10 \
            ${{ secrets.EC2_USER }}@${{ secrets.EC2_HOST }} "echo 'SSH connection successful'"
      - name: Deploy to EC2
        run: |
          ssh -i ~/.ssh/deploy_key -o StrictHostKeyChecking=no \
            ${{ secrets.EC2_USER }}@${{ secrets.EC2_HOST }} << 'EOF'
            cd /opt/wifi-qr-generator
            git fetch origin
            git reset --hard origin/main

            if [ ! -d "venv" ]; then
              python3 -m venv venv
            fi

            source venv/bin/activate
            pip install --upgrade pip
            pip install -r requirements.txt

            sudo systemctl restart wifi-qr-generator
            sudo systemctl reload nginx

            sudo systemctl is-active --quiet wifi-qr-generator && echo "Service is running" || echo "Service failed to start"
            EOF

The server-side deploy script (deploy.sh)

deploy.sh is intended for initial server bootstrap and can also be used for manual re-deploys. Below is an improved, annotated excerpt that you can place in your repo and run once on the EC2 instance during initial setup.

#!/bin/bash
set -euo pipefail

APP_DIR="/opt/wifi-qr-generator"
REPO_URL="https://github.com/YOUR_USERNAME/WIFI-QR-Code-Generator.git"
SERVICE_NAME="wifi-qr-generator"
USER="${SUDO_USER:-$(whoami)}"

echo "Starting deployment of WiFi QR Generator..."

sudo apt update
sudo apt upgrade -y
sudo apt install -y python3 python3-pip python3-venv nginx git

# Create app directory and ensure ownership
sudo mkdir -p "$APP_DIR"
sudo chown "$USER:$USER" "$APP_DIR"

if [ -d "$APP_DIR/.git" ]; then
    echo "Repository exists, pulling latest changes..."
    cd "$APP_DIR"
    git fetch origin
    git reset --hard origin/main
else
    echo "Cloning repository..."
    git clone "$REPO_URL" "$APP_DIR"
    cd "$APP_DIR"
fi

python3 -m venv venv
source venv/bin/activate
pip install --upgrade pip
pip install -r requirements.txt

# Example nginx config copy (ensure your repo includes nginx.conf file)
if [ -f "nginx.conf" ]; then
  sudo cp nginx.conf /etc/nginx/sites-available/$SERVICE_NAME
  sudo ln -sf /etc/nginx/sites-available/$SERVICE_NAME /etc/nginx/sites-enabled/$SERVICE_NAME
fi

# Create a systemd service file if not present (make sure the unit file is included in repo or create it)
if [ ! -f "/etc/systemd/system/$SERVICE_NAME.service" ]; then
  echo "Please add a systemd unit file at /etc/systemd/system/$SERVICE_NAME.service or include it in the repository."
fi

sudo systemctl daemon-reload
sudo systemctl enable --now $SERVICE_NAME
sudo systemctl enable --now nginx

echo "Deployment completed successfully!"
echo "Your application should be accessible at http://YOUR_EC2_PUBLIC_IP"
echo "To view logs: sudo journalctl -u $SERVICE_NAME -f"

Production systemd unit (example)

Ensure the service runs using the virtualenv’s Python interpreter and restarts automatically.

# /etc/systemd/system/wifi-qr-generator.service (example)
[Unit]
Description=WiFi QR Generator Flask App
After=network.target

[Service]
User=ubuntu
WorkingDirectory=/opt/wifi-qr-generator
Environment=PATH=/opt/wifi-qr-generator/venv/bin
Environment=FLASK_APP=app.py
Environment=FLASK_ENV=production
ExecStart=/opt/wifi-qr-generator/venv/bin/python app.py
Restart=always
RestartSec=3
StandardOutput=journal
StandardError=journal

[Install]
WantedBy=multi-user.target

Note: FLASK_ENV is used here for clarity in the demo, but in new Flask releases prefer using FLASK_DEBUG or explicit configuration within your application.

GitHub repository secrets (required)

Add these under Settings > Secrets and variables > Actions:

Secret name	Value
EC2_HOST	EC2 public IP (no protocol)
EC2_USER	e.g., ubuntu
EC2_SSH_KEY	full private key (PEM/ED25519) content, unencrypted

Never commit private keys or other secrets to the repository. Use GitHub Actions secrets. For CI/CD, use a dedicated deployment key (no passphrase) rather than your personal key.

Troubleshooting SSH authentication

Common failures:

ssh: this private key is passphrase protected
ssh: handshake failed: unable to authenticate

Recommended fixes: Option A — Create a dedicated deploy key (recommended)

ssh-keygen -t ed25519 -f ~/.ssh/ec2-deploy-key -N "" -C "github-actions-deploy"
ssh-copy-id -i ~/.ssh/ec2-deploy-key.pub ubuntu@your-ec2-ip
# Copy the private key into the EC2_SSH_KEY secret:
cat ~/.ssh/ec2-deploy-key

Option B — Remove passphrase from an existing key (not ideal)

ssh-keygen -p -f ~/.ssh/your-existing-key
# Press Enter to set an empty passphrase, then copy the private key into EC2_SSH_KEY.

Verify:

EC2_SSH_KEY contains the BEGIN/END lines and the full private key.
EC2 instance has the matching public key in ~/.ssh/authorized_keys for the deploy user.
EC2 security group allows inbound SSH (port 22) from your expected sources.
Test manually:

ssh -i ~/.ssh/ec2-deploy-key ubuntu@your-ec2-ip "echo 'test successful'"

Include the “Test SSH connection” step in your workflow to fail fast and make debugging easier.

Iterative troubleshooting (demo summary)

Initial automated runs failed due to passphrase-protected or incorrectly provisioned keys.
The author generated an ed25519 keypair, added the public key to the EC2 user’s authorized_keys, placed the private key into GitHub Secrets, and added a quick SSH test step to the workflow.
After an initial manual setup on the server (git clone and ./deploy.sh once), the automated workflow could reliably deploy subsequent changes.

A screenshot of a GitHub repository settings page showing "Actions secrets and variables" with a modal asking to confirm deletion of the secret named "EC2_SSH_KEY." In the background is a code editor/IDE window with project files and a terminal.

A screenshot of a developer desktop showing a GitHub repository's Actions page in dark mode with a "Deploy to EC2" workflow and several failed workflow runs listed. A code editor with project files is visible in the background.

Success verification

Once the SSH keys and initial server setup were correct, GitHub Actions successfully ran tests and deployed the app. The repository’s templates were updated (e.g., the site title), and the EC2-hosted site reflected those changes.

A screenshot of a desktop showing a GitHub Actions workflow run in a browser, with the "test" and "deploy" jobs marked successful. A code editor (Visual Studio Code) with project files is visible in the background.

A browser window is open to "KodeKloud's Awesome Wi-Fi QR Generator" showing a form with SSID "MyHomeWiFi", a password field, security dropdown, and a "Generate QR" button. Behind the browser is a code editor with project files visible.

Key lessons and best practices

Be explicit about the target environment (Ubuntu EC2, GitHub Actions) when scaffolding CI/CD.
Always store secrets in GitHub Actions Secrets; never commit them to source control.
Use a dedicated, passphrase-free deploy key for automation and rotate keys periodically.
Perform a one-time manual server initialization (clone and run deploy.sh) so automated runs can assume the repository layout.
Add an early “Test SSH connection” step to fail fast during debugging.
Understand the deployment pieces (SSH keys, service units, nginx, venv) to diagnose failures quickly.

Helpful references

Reference commands

SSH to EC2:

ssh -i ~/.ssh/ec2-deploy-key ubuntu@your-ec2-public-ip

Initial EC2 manual setup (run once if preferred):

sudo mkdir -p /opt/wifi-qr-generator
sudo chown ubuntu:ubuntu /opt/wifi-qr-generator
sudo git clone https://github.com/YOUR_USERNAME/WIFI-QR-Code-Generator.git /opt/wifi-qr-generator
cd /opt/wifi-qr-generator
chmod +x deploy.sh
./deploy.sh

Wrap up This guide demonstrates how to scaffold a CI/CD pipeline using GitHub Actions and a simple server-side deploy process for an Ubuntu EC2 instance. The assistant-generated pipeline and scripts provide a solid starting point, but expect to iterate on keys, permissions, and service configuration to reach a stable, secure deployment. Thank you for following along — after this setup, merging to main will run tests and automatically deploy the updated Flask application to your EC2 instance.

Introduction

Getting Started with Claude Code

Working with Claude Code

Code Review with Claude Code

Security Auditing with Claude Code

Advanced Features

Demo CICD Pipeline Setup

Overview

Quick file/resource map

Application (app.py)

What we want from CI/CD

GitHub Actions workflow (example)

The server-side deploy script (deploy.sh)

Production systemd unit (example)

GitHub repository secrets (required)

Troubleshooting SSH authentication

Iterative troubleshooting (demo summary)

Success verification

Key lessons and best practices

Helpful references

Reference commands

Watch Video

​Overview

​Quick file/resource map

​Application (app.py)

​What we want from CI/CD

​GitHub Actions workflow (example)

​The server-side deploy script (deploy.sh)

​Production systemd unit (example)

​GitHub repository secrets (required)

​Troubleshooting SSH authentication

​Iterative troubleshooting (demo summary)

​Success verification

​Key lessons and best practices

​Helpful references

​Reference commands

Watch Video

Overview

Quick file/resource map

Application (app.py)

What we want from CI/CD

GitHub Actions workflow (example)

The server-side deploy script (deploy.sh)

Production systemd unit (example)

GitHub repository secrets (required)

Troubleshooting SSH authentication

Iterative troubleshooting (demo summary)

Success verification

Key lessons and best practices

Helpful references

Reference commands
