DEMO Mozilla SOPS Developer

Learn how to encrypt and manage your Kubernetes secrets in Git using Mozilla SOPS with a PGP key, then let FluxCD decrypt them automatically on apply.

Prerequisites

A Git repository with your application code checked out.
Administrator-generated PGP keypair (public key committed in infrastructure/SOPS/).
FluxCD installed in your cluster.
gpg, git, wget, and kubectl available on your machine.

Prepare the Repository
Import the Public PGP Key
Install SOPS
Encrypt the Secret with SOPS
Commit and Push
Configure FluxCD Decryption
Verify Decrypted Secret in Cluster

1. Prepare the Repository

Switch to your infrastructure branch and restore the plaintext secret for re-encryption.

cd bb-app-source/
git checkout infrastructure

Always back up existing sealed or encrypted secrets before modifying them.

Action	Command
Backup old Bitnami Sealed Secret	`mv database/secret-mysql-sealed.yaml database/secret-mysql-sealed.yaml.bak`
Restore plaintext secret manifest	`mv database/secret-mysql-backup.yaml database/secret-mysql.yaml`

Verify the plaintext Secret at database/secret-mysql.yaml:

apiVersion: v1
kind: Secret
metadata:
  name: secret-mysql
  namespace: database
stringData:
  password: mysql-password-0123456789

2. Import the Public PGP Key

On a fresh developer machine, confirm you have no existing public keys:

gpg --list-public-keys
# -> (no keys found)

Import the administrator’s public key:

gpg --import infrastructure/SOPS/dev-us-e1-k8s.pub

Validate the import and note the fingerprint (e.g., CE284BB236654E42A):

gpg --list-public-keys
# gpg: key CE284BB236654E42: public key "dev.us.e1.k8s (k8s) <admin@bb.com>" imported

You will use the PGP fingerprint with the sops CLI to encrypt your secret.

3. Install SOPS

Install the SOPS binary if it’s not already present:

cd ~
wget https://github.com/mozilla/sops/releases/download/v3.7.3/sops-v3.7.3.linux.amd64
chmod +x sops-v3.7.3.linux.amd64
sudo mv sops-v3.7.3.linux.amd64 /usr/local/bin/sops

Confirm the installation:

sops --version
# sops version 3.7.3

4. Encrypt the Secret with SOPS

Navigate to the directory containing your plaintext secret:

cd bb-app-source/database
cat secret-mysql.yaml

Encrypt only the data and stringData sections in place:

sops --encrypt \
  --encrypted-regex="^(data|stringData)$" \
  --pgp CE284BB236654E42A \
  --in-place secret-mysql.yaml

After encryption, secret-mysql.yaml will include an sops: block:

apiVersion: v1
kind: Secret
metadata:
  name: secret-mysql
  namespace: database
stringData:
  password: ENC[AES256_GCM,data:...,iv:...]
sops:
  pgp:
    created_at: "2023-04-06T18:35:26Z"
    enc: |
      -----BEGIN PGP MESSAGE-----
      hQGMAxQRIka4bFJ8AQv/...
      -----END PGP MESSAGE-----
  mac: ENC[AES256_GCM,data:...]
  lastmodified: "2023-04-06T18:35:29Z"

Encryption Backends Supported by SOPS

Backend	Description
PGP	Public-key encryption via GnuPG / GPG
AWS KMS	Key management using AWS Key Management Service
GCP KMS	Google Cloud Key Management Service integration
Azure Key Vault	Microsoft Azure Key Vault integration
HashiCorp Vault	Vault secret engine encryption

5. Commit and Push

Add the encrypted secret to your Git repository and push:

git add database/secret-mysql.yaml
git commit -m "chore: encrypt secret-mysql.yaml with SOPS"
git push origin infrastructure

6. Configure FluxCD Decryption

FluxCD needs the private key stored in a Kubernetes Secret (e.g., sops-gpg) and decryption enabled in the Kustomization manifest. Edit infrastructure/flux/kustomization-database.yaml:

apiVersion: kustomize.toolkit.fluxcd.io/v1beta2
kind: Kustomization
metadata:
  name: infra-database-mysql
  namespace: flux-system
spec:
  interval: 10s
  path: "./database"
  prune: true
  sourceRef:
    kind: GitRepository
    name: infra-source-git
  targetNamespace: database
  decryption:
    provider: sops
    secretRef:
      name: sops-gpg

Commit and push the FluxCD configuration:

git add infrastructure/flux/kustomization-database.yaml
git commit -m "feat: enable SOPS decryption in Flux Kustomization"
git push origin infrastructure

For details, see FluxCD Kustomization Documentation.

7. Verify Decrypted Secret in Cluster

Trigger reconciliation and inspect the applied secret:

flux reconcile source git flux-system
flux reconcile kustomization infra-database-mysql

kubectl -n database get secret secret-mysql -o json \
  | jq -r .data.password | base64 -d
# => mysql-password-0123456789

You should see the original plaintext password, confirming that FluxCD decrypted the secret before applying it.
