Welcome to the final demo of this course. In this lesson, we’ll explore essential Nginx troubleshooting techniques—from syntax checks and graceful reloads to per-site logging, health checks, DNS resolution, and firewall configuration. These tips will help you diagnose and fix Nginx issues quickly, ensuring high availability for your applications.

​
1. Validate Configuration Syntax with nginx -t

Always verify your Nginx configuration after any edit. This prevents deploying broken configs that could take your server offline.
root@nginx:~# nginx -t
nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
nginx: configuration file /etc/nginx/nginx.conf test is successful
If there’s a typo (e.g., a missing semicolon), Nginx reports an error immediately:
root@nginx:~# nginx -t
nginx: [emerg] directive "deny" is not terminated by ";" in /etc/nginx/sites-enabled/example-https:9
nginx: configuration file /etc/nginx/nginx.conf test failed
Running nginx -t is a must step in your deployment pipeline to catch syntax errors early.

​
2. Understand Directive Contexts

Certain directives only work within specific blocks. For example, you cannot place an http { … } block inside a server { … } block:
server {
    listen 80;
    server_name example.com;

    # ❌ This will fail
    http {
        access_log /var/log/nginx/access.log;
    }
}
Testing this misplacement yields:
nginx: [emerg] "http" directive is not allowed here in /etc/nginx/sites-enabled/example-https:33
nginx: configuration file /etc/nginx/nginx.conf test failed
Always refer to the Nginx Directive Reference to confirm where directives are allowed.

​
3. Graceful Reload vs. Full Restart

Use a graceful reload to apply configuration changes without dropping active connections. A full restart will briefly disconnect users.
ActionCommandImpact
Graceful reloadnginx -t && nginx -s reloadNo dropped connections
Full restart (not ideal)systemctl restart nginxActive sessions are disconnected
# Preferred: Graceful reload
root@nginx:~# nginx -t && nginx -s reload

# Only if necessary: Full restart
root@nginx:~# systemctl restart nginx

​
4. Configure Per-Site Logging

When hosting multiple domains, separate logs per site for easier debugging.
Configuration FilePurpose
/etc/nginx/nginx.confGlobal defaults and includes
/etc/nginx/sites-available/exampleDomain-specific server blocks
/var/log/nginx/example.com/Dedicated log directory
  1. Global Logging Settings (/etc/nginx/nginx.conf):
    access_log  /var/log/nginx/access.log;
error_log   /var/log/nginx/error.log;
include     /etc/nginx/sites-enabled/*;
  2. Site-Specific Configuration (/etc/nginx/sites-available/example-https):
    server {
    listen 80;
    server_name example.com;
    return 301 https://$host$request_uri;
}

server {
    listen 443 ssl;
    server_name example.com;

    ssl_certificate     /etc/ssl/certs/example.com.pem;
    ssl_certificate_key /etc/ssl/private/example.com-key.pem;

    root /var/www/html;

    access_log /var/log/nginx/example.com/access.log;
    error_log  /var/log/nginx/example.com/error.log;

    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains; preload";
    add_header X-Frame-Options           "SAMEORIGIN";
    add_header Content-Security-Policy  "default-src 'self'";
    add_header Referrer-Policy          origin;

    index index.html index.htm;

    location / {
        try_files $uri $uri =404;
    }
}
  3. Create and Secure Log Directory:
    root@nginx:~# mkdir -p /var/log/nginx/example.com
root@nginx:~# chown www-data:adm /var/log/nginx/example.com
root@nginx:~# nginx -t && nginx -s reload
  4. Verify:
    root@nginx:/var/log/nginx# ll
drwxr-xr-x 2 www-data adm 4096 Feb 18 19:48 example.com/
root@nginx:/var/log/nginx/example.com# tail -f access.log

​
5. Perform Health Checks with curl

Use curl to isolate failures between network/DNS issues and Nginx itself:
  • Local HTTP check:
    root@nginx:/# curl localhost
  • HTTPS header inspection:
    root@nginx:/# curl --head https://example.com
HTTP/1.1 200 OK
Server: nginx/1.18.0 (Ubuntu)
  • Verify service is down:
    root@nginx:/# systemctl stop nginx
root@nginx:/# curl --head https://example.com
curl: (7) Failed to connect to example.com port 443: Connection refused

​
6. Ensure Local DNS Resolution

For accurate testing, map your domain to localhost in /etc/hosts:
# /etc/hosts
127.0.0.1   localhost example.com www.example.com
::1         ip6-localhost ip6-loopback

​
7. Verify Firewall Rules

Confirm both OS-level and cloud firewalls allow inbound traffic on ports 80, 443, and SSH (22):
root@nginx:/# ufw status
Status: active

To                         Action      From
--                         ------      ----
22/tcp                     ALLOW       Anywhere
80/tcp                     ALLOW       Anywhere
443/tcp                    ALLOW       Anywhere
22/tcp (v6)                ALLOW       Anywhere (v6)
80/tcp (v6)                ALLOW       Anywhere (v6)
443/tcp (v6)               ALLOW       Anywhere (v6)
If port 80 is closed, HTTP traffic can’t reach Nginx for redirection to HTTPS.
Unless you have advanced requirements, the defaults suffice. These common tweaks help improve security and performance:
# Disable legacy TLS and prefer strong ciphers
ssl_protocols       TLSv1.2 TLSv1.3;
ssl_prefer_server_ciphers on;

# Enable gzip compression
gzip on;
gzip_types text/plain text/css application/json application/javascript text/xml application/xml;
Thanks for joining this lesson—good luck with your deployments!
