Demo Working with nmcli

In this lesson you’ll learn how to manage network connectivity using nmcli, the command-line tool for NetworkManager. This demo walks through inspecting device status, creating a new Ethernet connection, verifying IP/routing/DNS, modifying addresses, and deleting the connection.

A dark-themed presentation slide with the title "Demo" and the subtitle "Working with nmcli" on the left. A large empty dark rectangle occupies the right side of the slide.

Callouts

Run nmcli commands as root (or with sudo) because most connection operations require privileges. You can inspect system-managed connection files under /etc/NetworkManager/system-connections/.

1. Check current devices and connections

Start by listing device status to discover available interfaces:

root@control:~# nmcli device status
DEVICE  TYPE      STATE      CONNECTION
enp0s3  ethernet  connected  enp0s3
lo      loopback  unmanaged  lo

Then list configured connections and the devices they are bound to:

root@control:~# nmcli connection show
NAME    UUID                                  TYPE      DEVICE
enp0s3  6f9c3bb8-fb17-38d3-93c0-e6cfa258782e  ethernet  enp0s3
lo      a8886d34-a666-4301-9bae-e6d2e7b4eda2  loopback  lo

2. Create a new Ethernet connection

In this example we’ll create a static IPv4 Ethernet connection with these parameters:

type: ethernet
ifname: enp0s3 (interface name)
con-name: custom-connection (human-friendly connection name)
ipv4.addresses: 10.0.2.18/24
ipv4.gateway: 10.0.2.1
ipv4.dns: 8.8.8.8
ipv4.method: manual

Run the add command:

root@control:~# nmcli connection add type ethernet ifname enp0s3 con-name custom-connection ipv4.addresses 10.0.2.18/24 ipv4.gateway 10.0.2.1 ipv4.dns 8.8.8.8 ipv4.method manual
Connection 'custom-connection' (75de3eb2-9883-4dd5-8bac-1b89ee0bb9c5) successfully added.

Verify the connection was created (note the DEVICE column shows -- when not active):

root@control:~# nmcli connection show
NAME                UUID                                  TYPE      DEVICE
enp0s3              6f9c3bb8-fb17-38d3-93c0-e6cfa258782e  ethernet  enp0s3
lo                  a8886d34-a666-4301-9bae-e6d2e7b4eda2  loopback  lo
custom-connection   75de3eb2-9883-4dd5-8bac-1b89ee0bb9c5  ethernet  --

To inspect the connection’s full properties:

root@control:~# nmcli connection show custom-connection

(That command prints the connection’s stored properties, such as IPv4/IPv6 settings, MAC address, autoconnect, and more.)

3. Activate the connection

Bring the connection up:

root@control:~# nmcli connection up custom-connection
Connection successfully activated (D-Bus active path: /org/freedesktop/NetworkManager/ActiveConnection/3)

Then verify the interface has the configured IP address:

root@control:~# ip addr show enp0s3
2: enp0s3: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc fq_codel state UP group default qlen 1000
    link/ether 08:00:27:f0:46:06 brd ff:ff:ff:ff:ff:ff
    inet 10.0.2.18/24 brd 10.0.2.255 scope global noprefixroute enp0s3
       valid_lft forever preferred_lft forever
    inet6 fe80::4c93:328c:c333:34cb/64 scope link noprefixroute
       valid_lft forever preferred_lft forever

Confirm the routing table shows the configured gateway:

root@control:~# ip route
default via 10.0.2.1 dev enp0s3 proto static metric 100
10.0.2.0/24 dev enp0s3 proto kernel scope link src 10.0.2.18 metric 100

Check DNS as configured by NetworkManager:

root@control:~# cat /etc/resolv.conf
# Generated by NetworkManager
nameserver 8.8.8.8

Do not edit /etc/resolv.conf manually when NetworkManager is managing it — changes may be overwritten. Configure DNS via nmcli or NetworkManager config files if you need persistent edits.

Test connectivity by pinging the DNS server and resolving a hostname:

root@control:~# ping -c 3 8.8.8.8
PING 8.8.8.8 (8.8.8.8) 56(84) bytes of data.
64 bytes from 8.8.8.8: icmp_seq=1 ttl=255 time=17.9 ms
64 bytes from 8.8.8.8: icmp_seq=2 ttl=255 time=18.1 ms
64 bytes from 8.8.8.8: icmp_seq=3 ttl=255 time=20.3 ms

--- 8.8.8.8 ping statistics ---
3 packets transmitted, 3 received, 0% packet loss, time 2004ms
rtt min/avg/max/mdev = 17.878/18.766/20.288/1.080 ms

root@control:~# ping -c 2 google.com
PING google.com (172.217.17.78) 56(84) bytes of data.
64 bytes from ams16s30-in-f78.1e100.net (172.217.17.78): icmp_seq=1 ttl=255 time=18.3 ms
64 bytes from ams16s30-in-f78.1e100.net (172.217.17.78): icmp_seq=2 ttl=255 time=19.7 ms

4. Modify an existing connection (add a second IPv4 address)

Use nmcli connection modify together with the + operator to append an IPv4 address:

root@control:~# nmcli connection modify custom-connection +ipv4.addresses 10.0.2.19/24

If the connection is active, reapply it to make changes take effect:

root@control:~# nmcli connection up custom-connection
Connection successfully activated (D-Bus active path: /org/freedesktop/NetworkManager/ActiveConnection/3)

Verify both IP addresses are present:

root@control:~# ip addr show enp0s3
2: enp0s3: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc fq_codel state UP group default qlen 1000
    link/ether 08:00:27:f0:46:06 brd ff:ff:ff:ff:ff:ff
    inet 10.0.2.18/24 brd 10.0.2.255 scope global noprefixroute enp0s3
       valid_lft forever preferred_lft forever
    inet 10.0.2.19/24 brd 10.0.2.255 scope global secondary noprefixroute enp0s3
       valid_lft forever preferred_lft forever

5. Delete the custom connection

When you no longer need the connection, remove it:

root@control:~# nmcli connection delete custom-connection
Connection 'custom-connection' successfully deleted.

Confirm removal:

root@control:~# nmcli connection show
NAME    UUID                                  TYPE      DEVICE
enp0s3  6f9c3bb8-fb17-38d3-93c0-e6cfa258782e  ethernet  enp0s3
lo      a8886d34-a666-4301-9bae-e6d2e7b4eda2  loopback  lo

Quick reference: common nmcli commands

Task	Command
List device status	`nmcli device status`
List configured connections	`nmcli connection show`
Add a connection	`nmcli connection add type ethernet ifname <iface> con-name <name> ipv4.addresses <addr/mask> ipv4.gateway <gw> ipv4.dns <dns> ipv4.method manual`
Show connection details	`nmcli connection show <con-name>`
Activate a connection	`nmcli connection up <con-name>`
Modify a connection (append)	`nmcli connection modify <con-name> +ipv4.addresses <addr/mask>`
Delete a connection	`nmcli connection delete <con-name>`

Links and references

NetworkManager documentation: https://networkmanager.dev/docs/
nmcli manual: man nmcli
Red Hat NetworkManager guide: https://access.redhat.com/documentation/en-us/red_hat_enterprise_linux/

This concludes the demo on using nmcli to create, modify, activate, verify, and delete NetworkManager connections.
