Demo Traffic Flow with Services and Ingress

Here’s a common problem every Kubernetes platform engineer encounters: Pods are ephemeral. They are created and destroyed frequently, and each pod gets a new IP address when recreated. If clients try to communicate using pod IPs directly, connectivity breaks when pods restart. Services solve this by providing a stable network endpoint and load-balancing to pods.

A presentation slide with the word "Demo" on the left and a blue curved panel on the right reading "Traffic Flow with Services and Ingress." The slide also shows a small "© Copyright KodeKloud" at the bottom left.

In this demo we will:

Reproduce pod churn and observe changing pod IPs.
Expose the app inside the cluster using a ClusterIP Service.
Expose it externally with a NodePort.
Add an Ingress (with an NGINX ingress controller) to demonstrate path-based routing to multiple backends.

Prerequisites and references:

Kubernetes cluster with sufficient permissions.
NGINX Ingress Controller installed (see the NGINX Ingress Controller docs: https://kubernetes.github.io/ingress-nginx/).
Docker images: NGINX (https://hub.docker.com/_/nginx) and HashiCorp http-echo (https://hub.docker.com/r/hashicorp/http-echo).

Create a deployment and observe pod churn

Create a Deployment named web using the NGINX image with three replicas, then inspect the pods:

controlplane ~ ➜ kubectl create deployment web --image=nginx --replicas=3
deployment.apps/web created

controlplane ~ ➜ kubectl get pods -o wide
NAME                        READY   STATUS    RESTARTS   AGE     IP          NODE         NOMINATED NODE   READINESS GATES
web-68d995574f-j4hpv        1/1     Running   0          15s     172.17.0.8  controlplane  <none>            <none>
web-68d995574f-njhqz        1/1     Running   0          15s     172.17.0.7  controlplane  <none>            <none>
web-68d995574f-q6hjj        1/1     Running   0          15s     172.17.0.6  controlplane  <none>            <none>

Now delete one pod and watch a new pod get created with a different IP:

controlplane ~ ➜ kubectl delete pod web-68d995574f-j4hpv
pod "web-68d995574f-j4hpv" deleted

controlplane ~ ➜ kubectl get pods -o wide
NAME                        READY   STATUS    RESTARTS   AGE     IP          NODE         NOMINATED NODE   READINESS GATES
web-68d995574f-4vgnb        1/1     Running   0          3s      172.17.0.9  controlplane  <none>            <none>
web-68d995574f-njhqz        1/1     Running   0          2m39s   172.17.0.7  controlplane  <none>            <none>
web-68d995574f-q6hjj        1/1     Running   0          2m39s   172.17.0.6  controlplane  <none>            <none>

Because the Deployment controller replaces deleted pods, the new pod has a different IP (172.17.0.9). Any client addressing the old pod IP would lose connectivity — which is why we use Services as stable access points to pods.

Expose the Deployment as a ClusterIP Service

Expose the web deployment as a ClusterIP Service (the default type) named web-svc:

controlplane ~ ➜ kubectl expose deploy web --port=80 --target-port=80 --name=web-svc
service/web-svc exposed

Describe the service to see how it maps to pods:

controlplane ~ ➜ kubectl describe service web-svc
Name:                     web-svc
Namespace:                default
Labels:                   <none>
Annotations:              <none>
Selector:                 app=web
Type:                     ClusterIP
IP:                       172.20.212.114
Port:                     <unset>  80/TCP
TargetPort:               80/TCP
Endpoints:                172.17.0.7:80,172.17.0.6:80,172.17.0.9:80
Session Affinity:         None
Events:                   <none>

Verify the pods have the label used by the Service selector:

controlplane ~ ➜ kubectl get pods --show-labels
NAME                      READY   STATUS    RESTARTS   AGE     LABELS
web-68d995574f-4vqnb      1/1     Running   0          117s    app=web,pod-template-hash=68d995574f
web-68d995574f-njhqz      1/1     Running   0          2m39s   app=web,pod-template-hash=68d995574f
web-68d995574f-q6hjj      1/1     Running   0          2m39s   app=web,pod-template-hash=68d995574f

ClusterIP services are reachable only from inside the cluster. To access the app externally, use NodePort or an Ingress.

Expose the app externally with NodePort

Create a NodePort Service named web-nodeport:

controlplane ~ ➜ kubectl expose deploy web --port=80 --target-port=80 --type=NodePort --name=web-nodeport
service/web-nodeport exposed

controlplane ~ ➜ kubectl get svc
NAME           TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)           AGE
kubernetes     ClusterIP   172.20.0.1       <none>        443/TCP           150m
web-nodeport   NodePort    172.20.11.172    <none>        80:30309/TCP      21s
web-svc        ClusterIP   172.20.212.114   <none>        80/TCP            2m1s

On a single-node cluster you can curl localhost with the assigned NodePort:

controlplane ~ ➜ curl localhost:30309
<!DOCTYPE html>
<html>
<head>
<title>Welcome to nginx!</title>
...
<h1>Welcome to nginx!</h1>
...
</html>

NodePort opens high-numbered ports (typically in the 30000–32767 range) on every node. It’s simple, but not user-friendly for end users, and it doesn’t provide host- or path-based routing or TLS termination. For host/path routing and easier external access, use an Ingress with an ingress controller.

Use Ingress for host/path-based routing (NGINX ingress controller)

Ingress is a cluster resource that defines routing rules (host/path) and optionally TLS termination. An ingress controller (e.g., NGINX) watches Ingress objects and programs a reverse proxy accordingly. Check that an NGINX ingress controller is running in the ingress-nginx namespace and that its Service is present:

controlplane ~ ➜ kubectl get pods -n ingress-nginx
NAME                                     READY   STATUS    RESTARTS   AGE
ingress-nginx-controller-c4d7b845b-bpzvx 1/1     Running   0          10m

controlplane ~ ➜ kubectl get svc -n ingress-nginx
NAME                        TYPE       CLUSTER-IP      EXTERNAL-IP   PORT(S)                         AGE
ingress-nginx-controller    NodePort   172.20.253.85   <none>        80:30080/TCP,443:30443/TCP      10m

Because the ingress controller Service maps node port 30080 → 80, hitting node:30080 reaches the ingress controller.

Add a second backend (api) for path-based routing

Create a second backend deployment api using HashiCorp’s http-echo image so it returns a simple response, then expose it as api-svc:

controlplane ~ ➜ kubectl create deploy api --image=hashicorp/http-echo --replicas=2 -- /http-echo --text="hello from kodekloud"
deployment.apps/api created

controlplane ~ ➜ kubectl expose deployment api --port=5678 --target-port=5678 --name=api-svc
service/api-svc exposed

Create an Ingress resource with path-based rules

Save the following as ingress.yaml (it rewrites paths to / and routes /api to api-svc:5678 and / to web-svc:80):

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: platform-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  ingressClassName: nginx
  rules:
  - http:
      paths:
      - path: /api
        pathType: Prefix
        backend:
          service:
            name: api-svc
            port:
              number: 5678
      - path: /
        pathType: Prefix
        backend:
          service:
            name: web-svc
            port:
              number: 80

Apply the Ingress and inspect it:

controlplane ~ ➜ kubectl apply -f ingress.yaml
ingress.networking.k8s.io/platform-ingress created

controlplane ~ ➜ kubectl describe ingress platform-ingress
Name:             platform-ingress
Namespace:        default
Address:
Ingress Class:    nginx
Default backend:  <default>
Rules:
  Host  Path   Backends
  ----  ----   --------
  *     /api   api-svc:5678 (172.17.0.11:5678,172.17.0.10:5678)
        /      web-svc:80 (172.17.0.7:80,172.17.0.6:80,172.17.0.9:80)
Annotations:     nginx.ingress.kubernetes.io/rewrite-target: /
Events:
  Type    Reason    Age   From                       Message
  ----    ------    ----  ----                       -------
  Normal  Sync      14s   nginx-ingress-controller  Scheduled for sync

Test the routing via the ingress controller NodePort (30080):

controlplane ~ ➜ curl localhost:30080/
<!DOCTYPE html>
<html>
<head>
<title>Welcome to nginx!</title>
...
<h1>Welcome to nginx!</h1>
...
</html>

controlplane ~ ➜ curl localhost:30080/api
hello from kodekloud

The same NodePort (30080) and cluster IP are now used by the ingress controller to route requests to different backends based on the paths defined in the Ingress resource.

Summary: the three routing layers

Ingress routes to Services, and Services route to Pods. Remember these three layers:

Layer	Purpose	Example / Notes
Ingress	External routing (host/path), TLS termination	`Ingress` resource handled by an ingress controller (e.g., NGINX).
Service	Stable internal discovery and load balancing to pods	`ClusterIP`, `NodePort`, `LoadBalancer`. `web-svc`, `api-svc`.
Pod	Actual application workload	Containers running NGINX or http-echo; pod IPs are ephemeral.

Debugging checklist (outside → inside)

Can’t reach the app externally?
- Verify the ingress controller pod(s) and Service are running.
- Confirm the ingress controller Service exposes ports (NodePort or LoadBalancer).
Ingress reachable but wrong backend?
- Inspect the Ingress resource: kubectl describe ingress <name>.
- Check annotations (e.g., rewrite rules) and ingressClassName.
Service has no endpoints?
- Check Service selectors and Pod labels: kubectl describe svc <svc> and kubectl get pods --show-labels.
- Confirm pods are listening on the expected targetPort.

When troubleshooting, always follow the chain: Ingress → Service → Pod. Verify the ingress-controller is running, the Ingress rules point to the correct services, and the Services select the appropriate Pods (labels and ports).
