config.yaml file. You’ll learn the configuration structure, how to wire receivers/processors/exporters into pipelines, how connectors enable cross-pipeline flows, and how to split and parameterize configuration for production use.
The Collector configuration is organized by component type. The primary groups are:
| Component | Purpose | Example |
|---|---|---|
| receivers | Ingest telemetry (traces, metrics, logs) | otlp receiving gRPC on 0.0.0.0:4317 |
| processors | Transform, filter, or batch data inside pipelines (optional) | batch, attributes |
| exporters | Send telemetry to backends | otlp, prometheus, debug |
| connectors | Bridge pipelines (acts as exporter and receiver) | count connector producing metrics from traces |
| extensions | Run outside pipelines (health checks, zPages, auth) | health_check, zpages |
| service | Declares enabled extensions and pipelines wiring | service.pipelines.traces |
Minimal required components for a running pipeline are a receiver and an exporter. If
service.pipelines is present, each pipeline must reference the relevant receivers and exporters.Minimal valid configuration
The smallest working Collector config needs a receiver to ingest data and an exporter to send it out. The following diagram shows a minimal pipeline: receiver → service.pipeline → exporter.
debug exporter that prints incoming spans to the console.
debug exporter is useful for testing because it logs the telemetry it receives.
Adding processors and extensions
Processors sit in pipelines to modify, filter, or batch telemetry. Extensions run outside pipelines and provide auxiliary features such as health checks and debugging pages. Example adding abatch processor and two extensions (health_check, zpages):
batch processor accumulates telemetry to improve throughput and reduce exporter load.
Multiple instances and pipelines
You can declare multiple instances of a component (different names) and multiple pipelines — even multiple pipelines for the same signal type. This enables routing telemetry to different backends or applying distinct processing. Example: two OTLP receivers on different ports, each routed to a different trace pipeline and exporter.otlpandotlp/ingest2are distinct receiver instances.tracesandtraces/2are independent trace pipelines.- Reusing a processor (like
batch) across pipelines is common.
Connectors: cross-pipeline flows
Connectors act as an exporter on one side and a receiver on the other, enabling telemetry conversion or flow between pipelines without an external process. This is useful for generating metrics from traces, for example. Example: count span events from production spans and expose them as a metric via a connector namedcount.
- The
countconnector inspects spans in the traces pipeline and applies the conditionattributes["env"] == "prod". - When a span matches, it emits a metric named
my.prod.event.count. - The metrics pipeline receives that metric via the
countreceiver and exports it (here, todebug).
Splitting configuration across files and parameterizing
The Collector supports including and merging multiple YAML files. Use${file:...} to include files and ${env:VAR:-default} for environment variable substitution. This pattern helps keep sensitive or environment-specific settings separate.
Main config.yaml example:
exporters.yaml example:
${file:exporters.yaml}, substitutes any environment variables, and merges everything into a single runtime configuration.
When splitting files, ensure included paths are correct and the merged configuration produces valid references (names in
service.pipelines must match declared component names). Test locally before deploying to production.Quick reference
- Minimum: receiver + exporter wired in
service.pipelines. - Common optional components:
processors(transform/batch) andextensions(health, zPages). - Use multiple instances and pipelines for flexible routing.
- Connectors bridge pipelines for conversions like traces → metrics.
- Use
${file:...}and${env:...}to modularize and parameterize configuration.
