Configuring ConfigMaps in Applications

In this lesson you’ll learn how to manage application configuration in Kubernetes using ConfigMaps. ConfigMaps let you separate non-sensitive configuration from Pod specs so you can manage settings centrally, avoid duplication across manifests, and make your deployments more maintainable.

A presentation slide titled "ConfigMaps" with a large dark-blue curved panel on the right featuring a white gear-and-wrench icon. The left side is mostly white with the "ConfigMaps" text centered and a small copyright notice at the bottom.

Why use ConfigMaps?

Reduce duplication of environment variables across many Pod manifests.
Separate configuration from container images and deployment logic.
Make configuration updates without rebuilding container images (depending on consumption method).

Basic workflow

Create a ConfigMap that contains key/value configuration data.
Inject the ConfigMap into one or more Pods as environment variables or mounted files.

Example key-value pairs we want to manage:

APP_COLOR: blue
APP_MODE: prod

Example: embedding env vars directly (NOT recommended at scale)

apiVersion: v1
kind: Pod
metadata:
  name: simple-webapp-color
spec:
  containers:
    - name: simple-webapp-color
      image: simple-webapp-color
      ports:
        - containerPort: 8080
      env:
        - name: APP_COLOR
          value: blue

When managing many manifests, duplicating values like the example above becomes hard to maintain. ConfigMaps solve this. Ways to create ConfigMaps There are two main approaches: imperatively with kubectl and declaratively with YAML manifests.

Method	When to use	Example
Imperative — from literals	Quick, ad-hoc values or one-off testing	`kubectl create configmap app-config --from-literal=APP_COLOR=blue --from-literal=APP_MODE=prod`
Imperative — from files	Load configuration from files (each filename becomes a key)	`kubectl create configmap app-config --from-file=app.properties`
Declarative — YAML manifest	Recommended for production: version-controlled, repeatable	See manifest example below and run `kubectl apply -f app-config.yaml`

Imperative creation (from literals)

Use --from-literal to add key/value pairs directly.

kubectl create configmap app-config \
  --from-literal=APP_COLOR=blue \
  --from-literal=APP_MODE=prod

Repeat --from-literal for additional keys. Good for a small number of items; less practical for many entries. Imperative creation (from files)

Use --from-file to create keys from file names. The file content becomes the value.

kubectl create configmap app-config --from-file=app.properties

If app.properties contains arbitrary content, the ConfigMap stores it under the key app.properties. Declarative creation (YAML manifest)

Preferred for repeatability and GitOps workflows. Create app-config.yaml:

apiVersion: v1
kind: ConfigMap
metadata:
  name: app-config
data:
  APP_COLOR: "blue"
  APP_MODE: "prod"

Apply the manifest:

kubectl apply -f app-config.yaml

You can create multiple ConfigMaps (for example mysql-config, redis-config) and name them to reflect their purpose. View and inspect ConfigMaps

List ConfigMaps:

kubectl get configmaps

Sample output:

$ kubectl get configmaps
NAME        DATA   AGE
app-config  2      3s

Describe a specific ConfigMap to inspect keys and values:

kubectl describe configmap app-config

Sample output:

$ kubectl describe configmap app-config
Name:         app-config
Namespace:    default
Labels:       <none>
Annotations:  <none>

Data
====
APP_COLOR:
----
blue
APP_MODE:
----
prod
Events:       <none>

How to inject ConfigMap data into Pods There are three common consumption patterns. Choose the one that best fits your application:

Consumption method	Description	Example
Import all keys as env vars (`envFrom`)	Expose every key in the ConfigMap as an environment variable	see `envFrom` example below
Single env var from a specific key (`valueFrom.configMapKeyRef`)	Map a specific ConfigMap key to a single env var	see `configMapKeyRef` example below
Mount keys as files (volume)	Each ConfigMap key becomes a file with the value as file content	see volume mount example below

Import all keys into environment variables (envFrom)

Use envFrom to import all key-value pairs from the named ConfigMap into the container environment:

apiVersion: v1
kind: Pod
metadata:
  name: simple-webapp-color
spec:
  containers:
    - name: simple-webapp-color
      image: simple-webapp-color
      ports:
        - containerPort: 8080
      envFrom:
        - configMapRef:
            name: app-config

This populates APP_COLOR=blue and APP_MODE=prod in the container environment.

Map a single key to a single environment variable

Use valueFrom.configMapKeyRef when you only need one specific key:

env:
  - name: APP_COLOR
    valueFrom:
      configMapKeyRef:
        name: app-config
        key: APP_COLOR

Mount ConfigMap keys as files in a volume

Mount the ConfigMap as a volume so that each key appears as a file under the mount path:

volumes:
  - name: app-config-volume
    configMap:
      name: app-config

containers:
  - name: simple-webapp-color
    image: simple-webapp-color
    volumeMounts:
      - name: app-config-volume
        mountPath: /etc/config

Files appear at /etc/config/APP_COLOR and /etc/config/APP_MODE, with file contents equal to the values. Best practices and important notes

ConfigMaps are not intended for sensitive data (such as passwords). Use Secrets for sensitive configuration. Also prefer declarative manifests (kubectl apply -f) for repeatability and version control.

Quick tips

Use clear, descriptive ConfigMap names because Pods reference them by name.
Prefer declarative YAML for production and CI/CD pipelines.
When mounting ConfigMaps as files, applications that read filesystem-based configs can pick up changes if they re-read files (watching/reload behavior varies by app).
To update a ConfigMap and ensure Pods pick up changes, you may need to restart or roll the Pods (depending on how the app consumes the data).

What we covered

Why separate configuration from Pod manifests.
How to create ConfigMaps imperatively (--from-literal, --from-file) and declaratively (YAML).
How to view and describe ConfigMaps (kubectl get / kubectl describe).
How to inject ConfigMap data into Pods using envFrom, valueFrom.configMapKeyRef, and volume mounts.

Links and references

Kubernetes ConfigMap documentation: https://kubernetes.io/docs/concepts/configuration/configmap/
Kubernetes API reference: https://kubernetes.io/docs/reference/generated/kubernetes-api/

Try it

Create a ConfigMap using the YAML manifest above.
Create the example Pod that consumes the ConfigMap.
Inspect the Pod environment or mounted files to confirm the ConfigMap values are available.
